10 Pcs 5a Lithium Charger Step Down 5a Power Supply Module Led Driver

US $26.70

ShengZheng ,GuangDong, China
Jun 9th

Open on mobile:
QR code

????? >Description 1?Input voltage range:6~38VDC(Note:input voltage not exceeding 38V) 2?Output voltage range:1.25-36VDC adjustable 3?Output current: 0-5A 4?Output power: 75W 5?High efficiency up to 96% 6?Built in thermal shutdown function 7?Built in current limit function 8?Built in output short protection function 9?Input reverse polarity protection: None (if required, high current diode in series with the input). 10?L x W x H =61.7*26.2*15mm 11?Weight: 20g Application 1?Use as a step-down modules with overcurrent protection capabilities Usage: (1) adjust the “voltage potentiometer” so that the output voltage reaches the value you want. (2) use a multimeter to measure the output short-circuit current with 10A stalls, while regulating the “current potentiometer” so that the output current reaches a predetermined overcurrent protection value. (For example, the meter displays the current value of 4A, then you can use the module to a maximum current of 4A) (3) Connected to the load. 2?Use as a battery charger Usage: (1) Make sure you need to charge the battery float voltage and charging current; (if lithium parameters 3.7V/2200mAh, then the float voltage is 4.2V, the maximum charging current 1C, ie 2200mA) (2) Under no-load conditions, adjust the “Voltage potentiometer” so that the output voltage reaches the float voltage; (if to 3.7V rechargeable lithium battery, the output voltage can be adjusted to 4.2V) (3) use a multimeter to measure the output short-circuit current with 10A stalls, while regulating the “current potentiometer” so that the output current reaches a predetermined Charging current value. (4) Charge turn lamp current factory default is 0.1 times the charging current; (Battery during charging current is gradually reduced, if the charge current setting is 1A, then when the charge current is less than 0.1A, blue lights turned off, the green light is on, which means that the battery is fully charged) (5) connected to the battery charge. (1,2,3,4 steps as: Output is unloaded, do not connect the battery) 3?Use as a LED constant current driver module Usage: (1) adjust the “voltage potentiometer” so that the output voltage reaches the value you want. (2) use a multimeter to measure the output short-circuit current with 10A stalls, while regulating the “current potentiometer” so that the output current reaches a predetermined LED operating current. (3) Connect LED, work. (1,2 steps as: Output is unloaded, do not connect LED) >Payment We only accept payment through Paypal. Items will go to post within 1-2 business days after payment confirmed. Please leave note in PayPal when making the payment if you have any special request (colors/size). >Shipping USA customers: all items will be shipped to address in buyer’s eBay details via ePacket service of USPS & China Post. We’ll offer tracking number for each package. Tracking info can be traced on USPS system. Customers outside of USA: all items will be shipped to address in buyer’s paypal details via Hong Kong post air mail. Before you bid item, please clear you have noticed below details: 7-25 working days: United States 10-25 working days: Canada, United Kingdom, Australia, Japan, New Zealand 2-5 working weeks: Countries in Western Europe, Southeast Asia, Israel, Korea 3-6 working weeks: Russia, Eastern Europe, Mid-East 4-7 working weeks: Mexico, South America Because of some post and custom reason, we ship item to worldwide but exclude the following countries and area: AFRICA: All countries in Africa; ASIA: Afghanistan, Bangladesh, Bhutan, Brunei, Cambodia, China, India, Iraq, Kazakhstan, Kyrgyzstan, Laos, Maldives, Mongolia, Nepal, Philippines, Singapore, Tajikistan, Turkey, Turkmenistan, Uzbekistan, Vietnam; Central America and Caribbean; South America: Colombia, Ecuador, Peru; EUROPE: Italy, Moldova, Romania. We are unable to take any responsibility for any custom delay or tax. Reason is because transit time is highly depended and provided by Postal Service (except weekends and holidays). >Contact Us Normally, we leave positive feedback for you once payment received. We are also hope that you can do me the same. Your support will keep us moving forward forever. If you are not satisfied when you receive your item, please return it within 30 days for a replacement or money back. Please contact me before you return it. If the shipping delay happened, we’re willing to pay refund or resend new item(s).

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	NEW
MPN	Does Not Apply
