10" precision horizontal and vertical rotary table, US $4700 – Picture 0
10" precision horizontal and vertical rotary table, US $4700 – Picture 0

10" Precision Horizontal And Vertical Rotary Table

US $4700

  • Norcross, Georgia, United States
  • Jun 3rd
Open on mobile:
QR code
Item No. 535 - 0410 Descriptions: This table is a high precision tool which can be used in either the vertical or horizontal position. It has the basic weight to stabilize vibrations and provide the rotary machining for which it was designed to accomplish. This unit will provide for all general shop usage. It has an oil bath lubrication system which allows for an extremely smooth turning operation. In general a very high quality shop tool which allows CNC type cuts to be performed on a manual machine.   Specifications: Diameter of table:  10"  ( 250 mm )   Morse taper center hole: MT3   Diameter of center hole:  1.1811" x 0.2362"    Center height for vertical mounting: 6.49"    Width of T-slot:  0.4724"    6 T - slots   Width of locating key: 0. 629"    Transmission ratio of worm gear: 1:90   Vernier reading:  10"   Indexing accuracy: 60"   Maximum working load: 485 lbs ( horizontally )   Maximum working load: 220 lbs ( vertically )   Surface to center slot squareness 0.0003" Taper center bore concentricity TIR 0.0005" Surface to base parallelism 0.0008" Surface to angle face squareness 0.0004" Cylinder center bore concentricity TIR 0.001" Dividing Plate and tailstock are optional   Any questions about the local pickup or info, call 678-232-7327 or at utoole.com
