(10) Wago 773-124 Wall-nuts Push-wire Marrette/nut

US $4.95

Janesville, Wisconsin, United States
Jan 29th

Open on mobile:
QR code

Wago WALL-NUTS™ PUSHWIRE™ Connectors M/N #: 773-124 Qty: 10 pcs. Specifications Wago Series: 773 Wago Product No: 773-124 Dimensions: 3/4 ” x 1/2 ” x 1/2 ” Connector Type: Pluggable Terminal Block No. of conductors: 4 (3 standard ports, plus 1 special port) Compatible Wiring: Cu/Cu only Standard Ports: 3 Solid: 18-12 AWG (.75 mm2 - 2.5 mm2) Stranded: 16-12 AWG (1.5 mm2 - 2.5 mm2), 19 strands max.; top-coated/pre-bonded/overcoated 22-16 AWG Special Port: 1 (Specially designed port for fixtures with pre-wired stranded leads) Solid: 18 AWG (.75 mm2) Stranded: 18 AWG (.75 mm2), 16 strands max; top-coated/pre-bonded/overcoated (double-tinned) *ports are filled with ‘Alu-Plus’ contact paste. Body Material: Polyamide Color/Colour: Light Gray, in clear housing Connector Retention Style: Spring Clip Contact Material: Steel Voltage: 600V, (1000V limited) Max. Temperature: 221? F (105? C) Approvals: UL listed, CSA certified, CE certified, RoHS Compliant *These Wall Nuts are for non-grounding terminations only FAST – SAFE – EASY Connect Stranded or Solid wire at the same connection WALL-NUTS™ are the first push-in connectors that connect both stranded and solid copper wires. Now you can use the speed and dependability of push-wire technology in every application. WALL-NUTS™ are UL listed and CSA certified for 600 volts. WALL-NUTS™ are perfect for new construction and retrofit work. WALL-NUTS™ work with 12-18 AWG solid and 12-16 AWG stranded wire, at the same junction, making main, branch and fixture hookup fast, easy and safe. No more hunting for the right size wire nut. Fast, Easy Installation The new WALL-NUTS™ push-in connectors makes the job of wire connecting easier. No more twisting and taping required. Simply strip the wire (7/16" to 1/2 "); insert the conductor and you’re finished. The integrated test port allows for continuity testing without reinsertion. To remove solid wire, just pull and twist. If the wire is stranded, cut the wire, discard the connector and re-strip the wire to insert it into a new connector. Safe WALL-NUTS™ hold each wire individually, eliminating loose connections. WALL-NUTS™ are touch-proof and rated to 105° C. WALL-NUTS™ are UL Listed/CSA certified for 600 volts (1000 volts for fixtures and signs) and current rated to the largest conductor used. See The Safety WALL-NUTS™ clear housing means you can see the firm connection of solid or stranded conductors. No more guessing whether the wires are twisted together or are pushed in far enough. Visual inspection allows you to see that WALLNUTS™ make reliable connections. The ergonomic advantages of WAGO Wire-Nuts are OSHA recognized, approved and recommended to reduce injuries and discomfort from wrist strain, while saving time and money. (http://www.osha.gov/SLTC/etools/electricalcontractors/supplemental/toolindex.html) (bottom of the page) Save Time WALL-NUTS™ provide up to 50% time savings on installation. Secure connections reduce expensive trouble shooting and warranty work. Special 18 AWG Stranded Range The 773-124 has a special opening that accepts 18 AWG stranded or solid; 18-22 tinned stranded copper. This makes the connection of incandescent light fixtures, dimmer switches, ceiling fans and other accessories to branch and main circuits a breeze. These items are factory new, manufactured in Germany by the Wago Corporation. Once you use these connectors you’ll never go back to Marrettes or any other twist-on wire-nut connectors. Your item will be shipped with your security/privacy in mind and to protect the unit(s) from damage during shipment. G Lot #1309 See the other items I have on offer at my eBay store. http://stores.ebay.com/sunroofguy

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Manufacturer	Wago
Model number	773-124
Series	773
G Lot	1309
