10 x DIP Switch 3 Positions 2.54mm Pitch Through Hole Silver Top Actuated Slide, US $4.49 – Picture 0
10 x DIP Switch 3 Positions 2.54mm Pitch Through Hole Silver Top Actuated Slide, US $4.49 – Picture 0

10 X Dip Switch 3 Positions 2.54mm Pitch Through Hole Silver Top Actuated Slide

US $4.49

  • shaoxing Zhejiang, China
  • Jan 29th
Open on mobile:
QR code
Lot10 DIP Switch 3 Positions 2.54mm Pitch Through Hole Silver Top Actuated Slide RED OR BULE Randomly send Number of Positions: 3 Circuit: SPST Switch Feature: Silver or Tin Plated Contacts Switch Type: Top Actuated Slide Mounting Type: Through Hole EACH BID FOR 10PCS Product performance   1.    Rated current:Switching currents 25Ma,24VDC 2.    Contact impedance:Initial value 50 milliohm After life test :100 milliohm 3.    insulation resistance minimum 500 megohm at500VDC 4.    Withstand Voltage:500VDC/one minute 5.    Operating force:maximum 1000gf 6.    Life test  5000times Material 1.   Cover with ontology:engineering plastic UL94V - 0 grade high temperature material, black 2.   Push button: engineering plastic UL 94 v - 0 high temperature engineering plastics material, white; 3.   Fixed contact and moving contact: copper tin plating or gold;. 4.   Pin: copper tin or gold 5.   Attached with a membrane, waterproof membrane The welding way 1.    Hand soldering: below 30 watts flipping: 350 degrees Celsius here not more than three seconds or 270 degrees Celsius within no more than five seconds 2.    Reflow soldering: 265 degrees Celsius within 30 seconds 3.    Wave soldering: 260 degrees Celsius for 10 seconds. We only accept paypal payment Satisfaction guaranteed. We refund or exchange the item if it's damaged or lost. The item should be returned within 7 days. Please contact us by email before return the goods. The shipping fee and insurance is not refundable. Any Question Please Contact Us By Ebay Message Thanks   Powered by eBay Turbo Lister  The free listing tool. List your items fast and easy and manage your active items.
