100' 350/3 W/grnd 600v Vfd Mc-hl Cca Ccw Continous Corrugated Aluminum Armor

US $720

Millville, New Jersey, United States
Jun 11th

Open on mobile:
QR code

Store Home View All Listings Store Policies Feedback Contact Us /a> Sign up to receive our Clearance list of wire and cable. General Interest 100' 350/3 W/GRND 600V VFD MC-HL CCA CCW Continous Corrugated Aluminum Armor Description Application: For use in harsh environments where maximum conductor protection is required. Impervious armor prevents the entrance of water, gas and corrosive elements into the electrical core. Used for power, control and lighting circuits in a broad range of commercial and industrial pulp and paper, mining, and petroleum applications. Approved for use in wet or dry locations at 90°C, installation indoors or outdoors, aerially, in conduits, ducts, cable trays or direct burial in circuits not exceeding 600 volts. UL listed, Type MC-HL per UL Standard 2225 for use in Class I, Division I hazardous locations. UL approved for use at 90°C for continuous operation, 130°C for emergency overload conditions, and 250°C for short circuit conditions. Impervious continuously welded and corrugated aluminum armor cable is recommended as an economical alternative to wire in conduit systems. Conductors: Soft bare annealed copper per ASTM B-3, Class B stranding per ASTM B-8 (compressed) or ASTM B-496 (compact). Insulation: Cross-linked polyethylene (XLP) per ICEA S-95-658 and UL Standard 44 for Type XHHW-2 conductors. Grounding Conductor: Soft bare annealed copper per ASTM B-3, Class B stranding per ASTM B-8 sized in accordance with NEC requirements. Armor: Impervious continuously welded and corrugated aluminum. Jacket: Black flame-retardant and sunlight-resistant PVC. Flame Tests: UL 1581 70,000 BTU/hr flame test ICEA 70,000 BTU/hr and 210,000 BTU/hr flame test IEEE 383 70,000 BTU/hr flame test Color Code: 14 AWG - 10 AWG: ICEA Method 1, Table E-2 8 AWG - 750 kcmil: ICEA Method 4 Additional Standards: UL listed Type CWCMC to IEEE 45/IEEE 1580 (46 CFR Part 111.60-23) Marine Shipboard Cable. Meets requirements of CSA-C22.2 No. 0.3, -40°C cold impact test. Connectors: Explosion Proof, Class I Division 1: 424MA series – all nickel-plated aluminum Rain Tight: 416MC series – all nickel-plated brass Size AWG/kcmil 350 No. of Conductors 3 No. of Strands 37 Insulation Thickness Mils 65 Jacket Thickness Mils 60 Ground Wire Size No.- AWG 3-6 Class 1 Div. 2 Connector No. 424MA08 Rain Tight Connector No. 416MC09 Armor Diameter Inch 2.22 Overall Diameter Inch 2.35 Net Weight Lbs/Mft 4560 Free shipping on most orders. Need the wire fast? Ask about our expedited shipping to get it to you on time. We accept PayPal and all major credit cards. All returns must be made within 30 days from the date of purchase or they will not be accepted. Feedback will be left as soon as feedback is left for us. Phone: 516-606-6537 Fax: 516-482-6438 Email: sales@nassaunationalcable.com
