100 Mhz, Vcxo Pll, Quartz Oscillator, Reference Synthesizer, Low Phase Noise

US $155.00

default, Russian Federation
Aug 11th

Open on mobile:
QR code

Quartz oscillator with low phase noise, with a phase locked loop of the PLL. 100 MHz VCXO_PLL Output frequency 100 MHz. 100 MHz VCXO_PLL is a voltage controlled crystal oscillator, in a narrow frequency band (100 MHz +/- 20 kHz), using a phase locked loop (PLL) system (integer synthesizer chip). Synchronized from the reference crystal oscillator 10 MHz. The choice of internal or external reference oscillator 10 MHz, carried out using the toggle switch (Fref_Ext / In) look at the photo. Internal dividers of a synthesizer microcircuit: R = 1, N = 10 The output frequency is related to the reference frequency, according to the formula: Fout = 10 * Fref_ext. Positive features of this device: - excellent frequency stability. - low phase noise (look at the photo). - high output power +12 dBm. - low current consumption of 150 mA, from a constant voltage source of +12 V. - selection of internal / external reference generator. - compact aluminum housing. Main technical characteristics (typical): Output frequency: 100MHz, (+/- 20kHz tuning) Output power: (+10 ... + 18) dBm Input and output impedance: Zout = Zin = 50 Ohm. Internal quartz oscillator: 10 MHz, +/- 20 ppm frequency accuracy, stable. Power supply: + 12 V, 150 mA. Input and output connector: SMA (mother) Block dimensions: 50.8mm * 50.8mm * 31.8mm. ------------------------------------------------------------------------------------------------------- Delivery: Track number is tracked, real number! Feel free to ask a question, contact me!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country/Region of Manufacture	Russian Federation
Termination Style	Connector
Material	Aluminum
Packaging	Box
Type	VCXO PLL Oscillator
Frequency Stability	+/-20ppm for internal reference oscillator
Oscillator Frequency	100 MHz
Brand	Pribor-Rf
Voltage Rating	+12 V / 260mA
