100 pcs/lot IC SN74LVC07ADR, Hex Buffer/Driver With Open-Drain Outputs, US $11.90 – Picture 0

100 pcs/lot IC SN74LVC07ADR, Hex Buffer/Driver With Open-Drain Outputs, US $11.90 – Picture 1

100 Pcs/lot Ic Sn74lvc07adr, Hex Buffer/driver With Open-drain Outputs

US $11.90

Shenzhen, China
Jan 29th

Open on mobile:
QR code

1 Features 3 Description This hex buffer/driver is designed for 1.65-V to 5.5-V 1• Operates From 1.65 V to 5 V • Inputs and Open-Drain Outputs Accept Voltages VCC operation. Up to 5.5 V Device Information(1) • Max tpd of 2.6 ns at 5 V PART NUMBER PACKAGE BODY SIZE (NOM) • Latch-Up Performance Exceeds 250 mA SOIC (14) 8.65 mm x 3.91 mm Per JESD 17 SSOP (14) 6.20 mm x 5.30 mm • Ioff Supports Live Insertion, Partial-Power-Down SN74LVC07A TVSOP (14) 3.60 mm x 4.40 mm Mode, and Back-Drive Protection TSSOP (14) 5.00 mm x 4.40 mm VQFN (14) 3.50 mm x 3.50 mm 2 Applications (1) For all available packages, see the orderable addendum at • AV Receiver the end of the data sheet. • Audio Dock: Portable • Blu-ray Player and Home Theater • MP3 Player or Recorder • Personal Digital Assistant (PDA) • Power: Telecom/Server AC/DC Supply: Single Controller: Analog and Digital • Solid State Drive (SSD): Client and Enterprise • TV: LCD, Digital, and High-Definition (HDTV) • Tablet: Enterprise • Video Analytics: Server • Wireless Headset, Keyboard, and Mouse 4 Simplified Schematic On Sep-30-14 at 19:34:39 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Texas Instruments
IC Package	SOIC14_39MM
Model	GoJGo.com-10333
Category	Logic IC, 74 serial
MPN	SN74LVC07ADR
