100mhz High Voltage Differential Isolating Oscilloscope Probe 1300v 50x 500x 8m?

US $630

Shenzhen, China
Jun 9th

Open on mobile:
QR code

Note: we'll ship this item via express mail service and ePacket to USA, Canada, Australia, New Zealand, Ireland, Austria, Belgium, Denmark, Germany, France, Finland, Luxemburg, Malta, Norway, Sweden, Swiss, Spain, Italy, UK, Japan, Korea,Thailand, Malaysia, Indonesia, Philippine, Singapore. Clients from other countries pls contact us in advance to confirm different shipping charges before you order. Introduction: IIP1000 series high voltage isolating probe applies differential input mode. It is used at the location need to measure high voltage or isolate from ground usually. IIP1000 series high voltage isolating probe supplies two attenuation ranges 1/50 and 1/500 to be selected. The Maximum measurable differential voltage are 130V (DC + peak AC) and 1300V (DC + peak AC) accordingly. IIP1000 series high voltage isolating probe has over range alarm function. It indicates with a red LED. IIP1000 series high voltage isolating probe is small and robust. It has very high stability, reliability and accuracy. It may be used at the following location usually: Measure without connect to ground Measure a high voltage or strong electricity Switch-mode power supplies design Power convert design AC inverter and UPS Transducer design Electronic ballast design Electromotor drive design CRT display design Electric and electronic experiment Electrical Specification Model IIP1025 IIP1050 IIP1100 Bandwidth (-3dB) 25MHz 50MHz 100MHz Rise time 14ns 7ns 3.5ns Accuracy +- 2% Attenuation 1/50, 1/500 Input resistance Between each input to ground: 4M? Between inputs: 8M? Input capacitance Between each input to ground: 7pF Between inputs: 3.5pF Maximum measurable differential voltage 1/50: 130V (DC + peak AC) 1/500: 1300V (DC + peak AC) Maximum input voltage-to-earth 1000Vrms, CATII 600Vrms, CATIII Noise 1/50: = 60dB 1MHz: >= 50dB Differential overvoltage detection level 1/50: 140V +- 4V (DC + peak AC) 1/500: 1400V +- 40V (DC + peak AC) AC adapter output DC9V, 1000mA AC adapter input AC100~240V, 50~60Hz Typical mechanical specification Input cable length IIP1025/IIP1050:60cm; IIP1100:30cm Output cable length 90cm Alligator clips 85x40x13(mm) Pincer clips 160x45x13(mm) Probe body 120x55x24(mm) Weight (probe only) 160g Environment Specification Operating temperature 0~40C Storing temperature -10~45C Operating humidity 85%RH Storing humidity 90%RH Operating altitude 3000m Storing altitude 12000m Packing list: High voltage isolating probe, 1pcs PDF Instruction manual , 1pcs AC adapter (US, Euro, AU or UK plug), 1pcs Red alligator clip, 1pcs Black alligator clip, 1pcs Red pincer clip, 1pcs Black pincer clip, 1pcs
