100mhz Tcxo 0.1ppm High Precision Temperature-compensation Crystal Oscillator P

US $21.99

Foshan, China
Jul 20th

Open on mobile:
QR code

The listing is 1 pcs 100MHZ TCXO 0.1ppm High precision Temperature-compensation active crystal Oscillator (CLOCK DIP14 +soldered on power supply board module) You will receive frequency same as the title, NOTE: DIY electronic skill&experience required! We provide customs works for TCXO: Wide Frequency: Range from 32.768KHZ to 200MHZ example:5MHz, 8MHz, 10.6445MHz, 16MHz, 22.5792MHz, 24MHz,24.576MHz, 25MHz, 49.1520MHz, 80MHz, 100MHz, 125MHz etc. Working voltage range for the buffer psu board: DC 7-10V PCB size: 48 x 35mm Description for the voltage regulate power supply: (1)This is an assembled board of clock buffer board to be used to replace the crystal in CD /DAC /Raspberry Pi etc. (2)The board contains integrated circuit to buffer the high stability oscillator so that the oscillator does not experienced any loading or digital interference from the CD player, while at the same time the clock signal can be fed to the board. (3)The board also include its own low noise low drop-out regulator to give the optimal power for the TCXO. (4) It can be used for clock source and frequency source in communications equipment and test instrument. Specification for TCXO: TCXO full name: Temperature Compensated Crystal Oscillator Power voltage for TCXO : +5.0V dc(± 5%) (+3.3Vdc also compatible) Power current : 20mA (MAX) Waveform : TTL/CMOS (we can make sinewave output if request) Duty cycle : 40/60% Frequency stability Vs Temp : +/- 1ppm (-10 ~ +60 ) Phase noise : -130dBc/1KHz@10M Frequency Accuracy: ±0.1ppm Max. Aging : +/- 2ppm/year jitter: 1ps max.,

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	Does Not Apply
Number of Pins	4
Brand	JYEC
Type	Oscillator
Oscillator Frequency	100MHZ
UPC	Does not apply
