100pcs Anritsu K103F Microstrip to K Female Flange Mount Connector 40GHz 50Ohm, US $1,400.00 – Picture 0

100pcs Anritsu K103F Microstrip to K Female Flange Mount Connector 40GHz 50Ohm, US $1,400.00 – Picture 1

100pcs Anritsu K103F Microstrip to K Female Flange Mount Connector 40GHz 50Ohm, US $1,400.00 – Picture 2

100pcs Anritsu K103f Microstrip To K Female Flange Mount Connector 40ghz 50ohm

US $1,400.00

Hong Kong, Hong Kong, Hong Kong
Jan 29th

Open on mobile:
QR code

Location: 02130 More than 4000pcs in stock! Please contact us if you want to buy more. Cross References: This part are same as following part from other manufacturers: 145-0701-602 BY JOHNSON 231CCSF BY CDI/TENSOLITE SF1552-6002 BY SV MICROWAVE 25-130-1500-90 BY SRI 1060031-1 BY TROMPETER 4852-3575-02 BY TYCO/AMP Datasheet is here: http://www.brightskyltd.com/data/pdf/k103f.pdf Here is another datasheet from Johnson, from where you can find all the cross references listed above, http://www.brightskyltd.com/data/pdf/johnsonrf.pdf Features Excellent Performance up to 40 GHz Performance Exceeding SMA Below 18 GHz Superior Reliability Compatibility with SMA, WSMA, and 3.5 mm Complete Testability on Existing Network Analyzers The K103F-R mates with either the K100 Bead or the K100B Hermetic Bead. The center pin to microcircuit interface can be accomplished in one of several ways. Anritsu has three different Stress Relief Contacts available. ("Sliding Contacts") All these contacts provide protection to the connection in the event of temperature changes, shock or vibration. The K110-1 is used for microstrip and Coplanar waveguide with 0.15 mm trace widths, the K110-2 is used for stripline with 0.41 mm trace widths, while the K110-3 is used for microstrip with 0.41 mm traces. When used with Coplanar Waveguide, some engineers use a pin-overlap design, which allows the pin to be soldered directly to the trace. Ribbon bonding can be used to connect the pin to the trace. The pin can be attached to the trace using silver epoxy. Several tools are used to manually install the bead and connector. Use the 01-106 soldering fixture to properly position the bead in a housing before soldering. This tool also is used with the K103M, K104F and K104M. Use the 01-104 Drill & Tap Set to simplify the job of drilling the required concentric holes in the housing; it is used when NOT using Stress Relief Contacts. Use the 01-108 Drill & Tap Set for the same purpose when Stress Relief Contacts are used. Connector Style SMK Connector Type Jack, Female Socket Contact Termination Solder Shield Termination Solder Impedance 50 Ohm Mounting Type Panel Mount, Flange (2 Hole) Cable Group - Fastening Type Threaded Frequency - Max 40GHz Features - Housing Color Silver Ingress Protection - Body Material Stainless Steel Body Finish - Center Contact Material Beryllium Copper Center Contact Plating Gold Dielectric Material - Voltage Rating 335V Operating Temperature -65°C ~ 165°C WE SHIP TO WORLDWIDE WITH TRACKING NUMBER! PAYMENT: We only accept payment through PayPal. Must be received within 5 days after auction ends. SHIPPING & HANDLING: All items are shipped by Hong Kong Postal Airmail Service within one working day after received payment. The shipping normally takes 7-14 business days. RETURN POLICE: ACCEPTED WITHIN 14 DAYS FROM THE DAY YOU RECEIVED GOODS.

Condition:	New: A brand-new, unused, unopened, undamaged item (including handmade items). See the seller's listing for full details. ...	Brand	Anritsu
Model	K103F
Country/Region of Manufacture	United States
MPN	K103F OR K103F-R
