100pcs/lot Reprap Stepper Driver A4988 Stepper Motor Driver Module Xiasongxin Li

US $103.27

Guangzhou, China
Aug 23rd

Open on mobile:
QR code

100pcs/lot Reprap Stepper Driver A4988 Stepper Motor Driver Module XIASONGXIN LI Brand Name:XIASONGXIN LIGHT Origin:CN(Origin) Condition:New Type:Voltage Regulator Model Number:A4988 Application:Computer Operating Temperature:A4988 Supply Voltage:A4988 Dissipation Power:A4988 is_customized:Yes A4988 is a complete microstepping motor driver with built-in translator for easy operation. This product is available in full, half, 1/4, 1/8 and 1/16 step modes operate bipolar stepper motors, output drive capacity of up to 35 V and ± 2 A. A4988 includes a fixed off-time current regulator, the regulator in slow or mixed decay modes. A4988 converter is the key to the easy implementation. As long as the "step" input inputting one pulse drives the motor one microstep. There are no phase sequence tables, high frequency control lines, or complex interfaces to program. A4988 interface is very suitable for complex microprocessor is unavailable or is overburdened. In the micro-step operation, A4988 chopping control inside automatically selects the current decay mode (Slow or Mixed). In mixed decay mode, the device is initially set to a fixed downtime in some fast decay, then the rest of the slow decay downtime. Mixed decay current control scheme results in reduced audible motor noise, increased step accuracy, and reduced power consumption. Internal synchronous rectification control circuitry is provided to improve the pulse-width modulation (PWM) operation power consumption. Internal circuit protection includes: thermal shutdown with hysteresis, undervoltage lockout (UVLO), and crossover-current protection. Special power sequencing. A4988 surface mount QFN package (ES), a size of 5 mm 5 mm, nominal overall package height of 0.90 mm, with an exposed pad for enhanced thermal dissipation. This package is Pb (suffix-T), with 100% matte tin leadframe plating. Features and Benefits · Low RDS (On) Output · Automatic current decay mode detection / selection · Mix with slow current decay modes · Synchronous rectification for low power dissipation · Internal UVLO · Cross-current protection · 3.3 and 5 V compatible logic supply · Thermal shutdown circuitry · Ground fault protection · Load short-circuit protection · Optional step five modes: full, 1/2, 1/4, 1/8 and 1/16 Package Included: 100 X A4988 Stepper Driver 100X Heatsink PLEASE NOTE: Our stock on eBay limited due to the way eBay works. However: If you need larger stock, please send us a message or visit our store. If you need very large stock (5 or more), please ask for offer, usually able to apply a extra discounts becouse of cheaper shipping costs.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Undisclosed
MPN	Does not apply
