1013d 7" Oscilloscope 2 Channels 100mhz*2 Band Width 1gsa/s Sampling Rate X6o3

US $190.00

Dayton, New Jersey, United States
Jul 22nd

Open on mobile:
QR code

1013D is a full-featured, highly practical, cost-effective dual-channel flat-panel oscilloscope for the maintenance and R & D industry. Features: Intelligent -burn, 1X can withstand up to 400V withstand voltage. 100MHz bandwidth @ 1GSa/s sampling rate1X = 5MHz10X = 100MHz. Fully fit 7 nch 800 * 480 resolution color TFT LCD display with bright colors and high contrast. Capacitive touching screen, the same as the touching mode of modern , is not a resistive touching screen with ancient nail operation. High measurement voltage , 1X can measure 0~40V, 10X can measure 0~400V100X can measure 0~4000V. Up to 12 parameters measurementVPP, VP, Vmax, Vmin, Vavg, Vrms, Frequent, Duty+, Duty-, +, -, Period. Cursor measurement function, it is convenient to manually measure the period and frequency and voltage. Complete triggering function (, normal, automatic). At any , the waveform display (pause function) is . Equipped with high efficiency -button AUTO. -button waveform storage and screenshot. Built-in 1GB storage space, can store up to 1000 screenshots + 1000 sets of waveform data. Powerful waveform picture manager supports thumbnail browsing, viewing, detailed viewing, page turning, deletion and waveform zooming in, zooming out, moving, etc. Equipped with a USB interface, which can be connected to a to share its screenshots with the , which is convenient for secondary analysis. Lissajous figures graphic display function can be used to determine the amplitude, frequency, and phase contrast of two groups of signals. FFT display function, can analyze the spectral characteristics of the signal. Built in 6000mAh rechargeable lithium , fully charged for 4 hours of continuous use at the highest screen brightness. Memory compression technology, waveform refresh screen does not flicker. Screen brightness adjustment. Background brightness adjustment. Ultra thin, easy to carry. Specifications: Material: ABS Color: black+white band width: 100MHz * 2 Number of channels: 2 channels Maximum real sampling rate: 1GSa/s Vertical sensitivity: 50 mV/div~500 V/div Horizontal base : 50S/div~10nS/div Maximum test voltage: 40V (1X probe), 400V (10X probe) Storage depth: 240Kbit Input resistance: 1M ADC accuracy: 8bits Coupling mode: AC/ Trigger mode: , Normal, Auto Trigger : Rising /Falling External trigger voltage: 0~40 V Display: 7 inch - 800*480 Operating: Capacitive touching screen + gesture Extension ports: USB picture export : 1 * lithium , 6000mAh (included) Item size: 184 * 124 * 50mm / 7.2 * 4.9 * 2.0in Package size: 230 * 150 * 60mm / 9.1 * 5.9 * 2.4in Package weight: 1000g / 2.2lb Packing List: 1 * 1013D Oscilloscope Host 2 * Matching 100MHz Probe (1X and 10X) 1 * USB Data Line 1 * User Manual (English) E13369

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	External trigger voltage	0~40 V
Trigger mode	Normal, Auto
Horizontal time base range	50S/div~10nS/div
Number of Channels	2 channels
ADC accuracy	8bits
Maximum real time sampling rate	1GSa/s
Vertical sensitivity	50 mV/div~500 V/div
Coupling mode	AC/
ASIN	B08K2R39ZY
Color	Black+white
Power supply	1 * lithium, 6000mAh (included)
Material	ABS
MPN	Does not Apply
Operating	Capacitive touching screen + gesture
Maximum Bandwidth	100
Brand	Unbranded/Generic
Oscilloscope Type	Digital Oscilloscope
Trigger edge	Rising /Falling
Item size	184 * 124 * 50mm / 7.2 * 4.9 * 2.0in
Maximum test voltage	40V (1X probe), 400V (10X probe)
Input resistance	1M
Extension ports	USB picture export
Features	Handheld/ Portable
Storage depth	240Kbit
Analog band width	100MHz * 2
Display	7 inch - 800*480
UPC	Does not Apply
