101sx 2 Layer 1"x1"plated Smd Thru-hole Circuit Proto Prototype Pcb Board

US $150

  • San Jose, California, United States
  • May 27th
                                                     MeasureExplorer prototype board product: 101SX, Double Layer, plated thru-hole 1" x 1" Board, 16                                                                            You get 16 boards in the package! Features: ME-PB-101SX This board combine surface mount solder pads and thru-hole solder pads together. All SMD pads are electrically connected through 10mil traces, user can simply remove the unnecessary traces in prototyping to create a clean and stable circuit. FR4 base material Double copper layer prototype board  Plated through holes with diameter 39mil and surface mount solder pads, 0.1 inch grid Square shape with length 1.0" 1 4-40  screw holes is located
