10mhz Ocxo Crystal Oscillator Frequency Standard Reference Proto/breakout Pcb

US $19.99

Olathe, Kansas, United States
Sep 3rd

Open on mobile:
QR code

10 MHz OCXO Breakout board - Includes CTI OSC5A2B02 Description of sale: A custom designed PCB to allow easy access to and experiments with an ovenized crystal Oscillator. The PCB includes a suitable 5 VDC power supply capable of providing the start up current and the required operation current (approx. 450mA and 200mA) The oscillator output which is a square wave at 10 MHz is available on a BNC jack and at a header position. The CTIOSC5A2B02 like many of these OCXO has the ability to be voltage controlled to 'trim' the frequency. This trim voltage can be from an ADC possibly a GPS controlled unit to achieve high accuracy. The trim voltage is applied to another of the header positions on the PCB. If the oscillator is not required to be highly accurate an on-board 25 turn potentiometer can be connected into circuit by bridging two solder pads. The 25 turn potentiometer allows easy manual adjustment of the final frequency as the oscillator free runs. This unit is available in 2 formats, a fully built unit ready to use or a bare bones unit that just comprises the PCB, Oscillator block installed and a BNC jack. Headers (both male and female) are also supplied with both formats. What's Included? Full unit; 1. Fully populated PCB as per photographs 2. Set of male and female header strips Barebones; 1. PCB with oscillator and BNC installed 2. Set of male and female header strips Notes Please be aware, the PCBs and components other than the oscillator block are all new items. The oscillator is a pull from other equipment and while fully tested by us will have cosmetic defects, such as marring, scuffs, dings and dents, marks etc. The sale is only for the oscillator breakout PCB, any test equipment seen in photographs is for illustration only and not part of this sale. Questions We always respond to questions about the product for sale - please ask before making your purchase, if any details are unclear or you need clarification. Remember the photos are also part of the sale description. Other Details: 1. USPS Shipping is free within the USA, we no longer ship outside the USA, please don't ask. 2. We ship in one business day after receipt of full payment. 3. Please make sure your ship to address is correct with ebay, this reduces shipping delays and issues. 4. Returns - start a return by accessing ebay customer support on your ebay account page, we generally offer 60 day return windows. 5. We provide follow up technical support after sale if needed - we are only an email away. About Feedback: We always leave positive feedback after shipping your item, no exceptions. Our products and service are all designed to give you the customer a 5 Star experience, however, we understand that sometimes things can go wrong (we are only human), and occasionally we may not meet our high standards or your expectations. Before leaving less than 5 Star feedback, or Neutral/Negative feedback for us, please give us an opportunity to resolve the situation to your satisfaction first. We are only an email away and will always respond.

“PCB and all components EXCEPT the OCXO are brand new. The OCXO is a tested used item that has been re-furbished. The OCXO will show some signs of wear, including scratches, small dents and dings etc. but is fully tested and guaranteed operational”

Modified Item

Custom Bundle

Country/Region of Manufacture

United States

Brand

CTI

MPN

Does not apply
