10pc Deca Socket Illuminated Pushbutton Switch C1s01t51 Dpdt Maintained 12v Lamp

US $92.60

Taipei county,, Taiwan, Taiwan
Jan 29th

Open on mobile:
QR code

SquareTrade © AP6.0 DECA Socket type Illuminated Pushbutton Switch C1S01T51 series With AC/DC 12V LED Lamp, Complete Part No. : Yellow LED : C1S01T51JY-H01, White LED : C1S01T51JY-H01, Blue LED : C1S01T51JB-H01, Green LED : C1S01T51JG-H01, Red LED : C1S01T51JR-H01 ?16mm, Rectangular, AC/DC12V LED Lamp IP40 waterproof Safety : UL CE Maintained, lock-type http://www.deca-switchlab.com/pdf/C1_PDF/Illuminated_Pushbuttons.pdf Deca co., Taiwan Switch : Maintained / lock, ON-OFF Pushbutton Switcher, 6pins : 2a & 2b Electric rating : AC250V 2A, DC30V 1A Cover / LED Colors : Red, Yellow, Green, Blue, White Indicate Size : 24.0x18.0mm, Rectangular Mounting Hole : ?15.5~16.0mm, Dia Overall length : 40.5mm Socket type Terminal : 6pins for Switcher, 2pins for LED Lamp Switch system : each contact block has one double break, snap action switching mechanism. Contact material : soldering type - silver is standard. Body material : high-grade temperature thermoplastic. Contact housing moulded in electrical high-grade thermosetting plastic. Operating travel : 3.0 mm. Actuating force : 2-5N depending on no. of contact block. Mechanical lifetime : > 2 million operations. Note : Please tell me the "Cover color" after order. Each bidding lot is for 10 pcs Net weight approx : 100g, 10pcs LT*N175x10 0.675 28 20141129+150g+20g+G7+Chiang Combine shipping with other items to reduce shipping cost are welcome. Will ship worldwide by post EMS or Airmail or SAL or Surface parcel package with insurance (if could). The delivery is about : EMS=3~5days, Airmail= 2 weeks, SAL=45days, Surface=2~3months, but no warranty if delay, depend on the post/customs. If you need the more the fastest delivery, take EMS please, but more expensive. For parcel weight =0.1~0.5Kg, the shipping cost= Argentina : $34.5(EMS), $26(Airmail), all with insurance, Australia : $28(EMS), $18(Airmail), all with insurance, Austria : $27.5(EMS), $16.5(Airmail), all with insurance, Belarus : $27.5(EMS), $24.5(Airmail), all with insurance, Belgium : $27.5(EMS), $22(Airmail), all with insurance, Brazil : $34.5(EMS), $25(Airmail), all with insurance, Canada : $27.5(EMS with insurance), $14(Airmail without insurance), Croatia : $17.5(Airmail with insurance), Cyprus : $27.5(EMS), $16(Airmail), all with insurance, Czech Rep. : $27.5(EMS), $19.5(Airmail), all with insurance, Denmark : $27.5(EMS), $17(Airmail), all with insurance, France : $27.5(EMS), $25(Airmail), all with insurance, Germany : $27.5(EMS with insurance), $17(Airmail without insurance), Great Britain : $27.5(EMS with insurance), $20(Airmail without insurance), Greece : $27.5(EMS), $19.5(Airmail), all with insurance, Hong Kong : $19(EMS), $15(Airmail), all with insurance, India : $23(EMS), $17(Airmail), all with insurance, Indonesia : $23(EMS with insurance), $18.5(Airmail without insurance), Israel : $23(EMS with insurance), $17.5(Airmail without insurance), Italy : $27.5(EMS), $25(Airmail), all with insurance, Japan : $23(EMS with insurance), Hong Kong : $19(EMS), $15(Airmail), all with insurance, Korea Rep. : $23(EMS), $14.5(Airmail), all with insurance, Malaysia : $23(EMS), $12(Airmail), all with insurance, Netherlands : $27.5(EMS), $17(Airmail), all with insurance, New Zealand : $23(EMS), $19.5(Airmail), all with insurance, Norway : $27.5(EMS with insurance), $23.5(Airmail without insurance), Philippines : $23(EMS), $15(Airmail), all with insurance, Russian Federation : $27.5(EMS with insurance), Saudi Arabia : $23(EMS with insurance), $17.5(Airmail without insurance), Singapore : $23(EMS), $14.5(Airmail), all with insurance, Slovak Rep. : $27.5(EMS), $19.5(Airmail), all with insurance, Slovenia : $27.5(EMS with insurance), $16.5(Airmail without insurance), South Africa : $34.5(EMS), $22(Airmail), $17.5(Surface), all with insurance, Spain : $27.5(EMS with insurance), $17.5(Airmail without insurance), Sweden : $27.5(EMS), $19.5(Airmail), all with insurance, Switzerland : $27.5(EMS), $17(Airmail), all with insurance, Thailand : $23(EMS), $15(Airmail), all with insurance, Turkey : $23(EMS with insurance), Ukraine : $27.5(EMS), $24.5(Airmail), all with insurance, USA : $27.5(EMS), $15(Airmail), all with insurance, Viet Nam : $23(EMS with insurance), other countries contact for detail shipping cost please. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer’s responsibility. Please check with your country’s customs office to determine what these additional costs will be prior to bidding/buying. Thanks for your looking.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	DECA
Country/Region of Manufacture	Taiwan
Model	C1S01T51 DPDT Maintained Look + AC/DC 12V LED Lamp
Country of Manufacture	Taiwan, Province of China
