10pcs Arduino Rtc Ds1302 Real Time Clock Module For Avr Arm Pic Smd New

US $9.17

Yancheng , ???, China
Mar 29th

Open on mobile:
QR code

10PCS Arduino RTC DS1302 Real Time Clock Module For AVR ARM PIC SMD NEW Product Descriptions DS1302(without battery) is introduced trickle charge the clock chip, containing a real-time clock / calendar and 31 bytes of static RAM, via a simple serial interface to communicate with the microcontroller. Real-time clock / calendar circuit provides seconds, minutes, hours, days, weeks, months, years of information, the number of days per month and leap year automatically adjust the number of days. Clock can be done by the AM / PM or 12 decided to use 24 hour format. Between the DS1302 and the microcontroller can simply use the synchronous serial communication mode, used only three port lines: (1) RST Reset (2) I / O data lines (3) SCLK serial clock. Clock / RAM read / write data to a byte or up to 31 bytes of character set way communication. DS1302 low-power work to maintain the data and clock information when power is less than 1mW Real time clock with the year 2100 to calculate the seconds, minutes, hours, days, weeks, months, years, the ability, as well as the ability to leap year adjustment 1.31 8 temporary data storage RAM 2.Serial I / O port pin makes the least number of ways 3.Wide range of operating voltage 2.0 5.5V 4.Current 2.0V, less than 300nA 5.Read / write clock or RAM data transmission when there are two single-byte transmit and multi-byte character sets transfer mode 6.8-pin DIP package or optional 8-pin SOIC package assembly according to the surface 7.simple 3-wire interface 8.Vcc = 5V and TTL-compatible 9.Optional industrial temperature range -40 to +85 10.Dual power tube for the main power and backup power supply Parameters: 1.PCB a single panel, size: 42mm * 24mm * 12mm(max) Net weight:10g Package weight:20g Color:green (as the picture shows) 2 with 4 holes, about 3.1mm in diameter 3 genuine spare battery for the celestial sphere CR2032, Voltage 3V, current is 260mAh, non-rechargeable batteries. 4 Crystal 32.768KHz, matching capacitance 6pF, size 2 * 6mm 5.DS1302 made large 8-pin DIP chip, chip, IC Block below for easy replacement and plug the chip 6 module operating voltage compatible 3.3V/5V, 5V and 3.3V microcontrollers can be connected with 7 Operating temperature: 0°C --- 70 °C NOTE: Wiring (to provide the program, for example, can take any IO port, the port defined in the program can be modified): VCC -> +5 V/3.3V GND -> GND CLK -> P02 DAT -> P01 RST -> P00 1.VCC and GND must not be reversed, or it will burn the chip 2.51 MCU P0 port requires a pull-up, if your single-chip pull-up resistor is not connected, you can port the data cable to the other Payment Payment Payable To Note PayPal All payments are due within 7 days of the close of auction. Failing to do so, non-paying bidders will be reported to eBay. Shipping Policy Delivery Time We ship to worldwide, it usually takes 10-30 Business Days to delivery. Shipping address We ship to your PayPal address. Please, make sure to provide us with correct, precise, and detailed shipping Address. Send Time Items will be shipped within 1 to 3 business days upon payment received or cleared. Note If you don't receive items over 30 business days, please notify us via eBay message. Return Policy We appreciate your business and offer an instant 7 days return policy.(7 days after receive the item). The returned item has to be in its original condition. We are able to refund your money without shipping cost. Contact us For anything about product, price, shipping or order status, please contact us via eBay message. We love positive feedback and 5 scores DSR. We will leave it for everyone that leaves it for us.
