2016060402531158196 2016060402531158196 MassDuino Nano Lower Price Micro USB Connector CH-340 USB to UART chip Arduino IDE Support Highly compatible to Arduino Nano 3.0 32KB Flash 2KB RAM 10/12/16Bit ADC /*====================================================== analogRead() // 10bit ADC, Compatible to UNO R3 analogRead_12bits() // 12bit ADC , 130 sps analogRead_16bits() // 16bit ADC , 125 sps ======================================================*/ Chip level support (MD-328D IC Lower to 0.6USD for mass purchase,click to view) Easy for prototype development , directly use for mass production! Features MD-328D 32KB Flash 2K SRAM Onboard 5V Regulator and 3.3V LDO Standard USB2Serial interface for uploading and debugging 3.3V and 5V system power voltage selectable 100% Arduino development environment Full NANO IO supported Parameters MCU: MD-328D 32K Flash 2K SRAM 16bit ADC Working Voltage : 3.3V and 5V Selectable Input Voltage: DC 5.5 to 12V 3.3V Output Current : 300mA MAX Bootloader preprogramming : Massduino MD-328D Upload sketch and communication Download and install Arduino IDE : https://www.arduino.cc/en/Main/Software Download Massduino support package: http://www.inhaos.com/downcount.php?download_id=218 Install Massduino support package: http://www.inhaos.com/uploadfile/otherpic/UM-MASSDUINO-V3.0-EN.pdf Download USB to UART cable driver : UC-340G: http://www.inhaos.com/downcount.php?download_id=193 Write code , uploading sketch , enjoy it! Package List 10 x MassDuino Nano Brand INHAOS MPN 13-20-Massduino-Nano UPC Does not apply Country/Region of Manufacture China Electronic in-house 10pcs Massduino Arduino Nano V3.0 MD-328D Micro USB 5V 3.3V Selectable 16MHz UNO MassDuino Nano Lower Price Micro USB Connector CH-340 USB to UART chip Arduino IDE Support Highly compatible to Arduino Nano 3.0 32KB Flash 2KB RAM 10/12/16Bit ADC /*====================================================== analogRead() // 10bit ADC, Compatible to UNO R3 analogRead_12bits() // 12bit ADC , 130 sps analogRead_16bits() // 16bit ADC , 125 sps ======================================================*/ Chip level support (MD-328D IC Lower to 0.6USD for mass purchase,click to view) Easy for prototype development , directly use for mass production! Features MD-328D 32KB Flash 2K SRAM Onboard 5V Regulator and 3.3V LDO Standard USB2Serial interface for uploading and debugging 3.3V and 5V system power voltage selectable 100% Arduino development environment Full NANO IO supported Parameters MCU: MD-328D 32K Flash 2K SRAM 16bit ADC Working Voltage : 3.3V and 5V Selectable Input Voltage: DC 5.5 to 12V 3.3V Output Current : 300mA MAX Bootloader preprogramming : Massduino MD-328D Upload sketch and communication Download and install Arduino IDE : https://www.arduino.cc/en/Main/Software Download Massduino support package: http://www.inhaos.com/downcount.php?download_id=218 Install Massduino support package: http://www.inhaos.com/uploadfile/otherpic/UM-MASSDUINO-V3.0-EN.pdf Download USB to UART cable driver : UC-340G: http://www.inhaos.com/downcount.php?download_id=193 Write code , uploading sketch , enjoy it! Package List 10 x MassDuino Nano Item Specifics Brand INHAOS MPN 13-20-Massduino-Nano UPC Does not apply Country/Region of Manufacture China Payment We accept Paypal payment only. Thanks for your understanding. Payment should be completed within 4 (Four) days of auction closing. Or unpaid dispute will be filed for closing auction. We will leave a positive feedback immediately after payment is received. We appreciate a positive feedback as much as you do. If for some reason there is any issue with the purchase, please contact us prior to leaving feedback, and we will be glad to work with you to have it resolved. Shipping Ship from GuangDong China, and only to your eBay address. Please update your latest address before you check out. and please make sure to provide us with correct, precise, and detail shipping address.Once your payment is completed, pls inform us by leave ebay note if the changes are needed before we send the product. Package handling only takes 1 business day at our warehouse(excluding Sat, Sun & Holiday). Orders placed on weekend will be shipped within 2 days. If an address change is needed, you will be responsible for any fees associated in the condition that you contact us after we ship your item. We only provide tracking number for standard shipping or above. If still need a tracking number, please contact us when you place an order. For countries that are a little far away, especially South America, it is suggest that you add a tracking number for your order, in case of losing parcels. Returns We absolutely stand behind our products. We also offer a 14 day money back guarantee should you be unhappy for any reason whatsoever. We ensure all our items are new and in excellent condition prior to shipping. In the event that you receive the item that is not to the standards above, please contact us via eBay messages. Please note that all returns must be pre-approved by LinkedTron. Unauthorized returns will not be accepted. If you need to return, please check twice to confirm the item not work and contact our customer service representative, let us know the detailed problem and send us some pictures for confirmation. We reserve the right to refuse any returns for objective reasons Customer Services 1. All inquiries will be replied in 24-48 working hours. 2. Our aim is 100% customer satisfaction! WE GUARANTEE BUYER WILL RECEIVE ITEM THEY ORDERED OR THEIR MONEY BACK. Please contact us with topic “Send/Ask seller a question” 3. If item not receive within estimate delivery date or item not as describe, we will refund with NO QUESTION ASK. Q&A Q: Item not received or item received not as describe? A: FULL refund or resend with no question ask. We guarantee buyer will receive item they ordered within estimate delivery date or their money back. Q: How do I pay for my purchase? A: We only accepts the payment method Paypal. Q: When will the item be shipped out? A: The item will be shipped within 1 business day once payment completed. Q: Where do you ship from? And how long does it take? A: The item ships from China. For US buyers, it will take 1-2 weeks to deliver; for non-US buyers, it will take 4-6 weeks to deliver. Q: Where is my tracking number? A: For international economy shipping, there is no tracking available. If you want a tracking, please choose the Standard shipping. Electronic in-house Welcome to momo_w20 ! Search Shop Category ◆ Store Home ► Analog Signal Process ◈ Precision Voltage Reference ◈ PWM DAC Module ◈ High Side Current Sense ► Power Supply Module ◈ AC-DC Power Module ◈ DC-DC Power Module ◈ Fixed Output Power Bank ► Arduino Compatible ◈ Arduino Kits ◈ Arduion Main Board ◈ Arduino Shield ◈ Sensors ◈ Arduino Car ◈ Arduino DAQ ► RF Module ◈ 2.4GHz RF Module ◈ 433MHz RF Module ◈ Bluetooth UART Module ► Interface ◈ USB to UART Convertor ► Components ◈ Sensor ◈ Diodes, Transistors, MOSFET ◈ Crystal ◈ Resistors ◈ Capacitors ◆ Tools ► Instrument ◈ Multimeters ◈ Audio Instrument ◈ Accessory ► Development Kit ◈ Programmers and Emulators ► Connector ◈ Audio Cable ◈ USB Cable ◈ Wire ◈ Female Header ◈ Pin Header ◆ Wireless Module ◆ 3D Printer ◆ AVR Programmer ◆ MassDuino ◆ Home Electronic ► LED/LAMP ◈ LED Cable ◈ LEDs ◆ LCD/TFT Display ► Power Chip ◈ Linear Regulator ◈ LDO ◈ Voltage Reference ◈ DC-DC Chip ► Amplifier ◈ Audio Amplifiers ► MCU ◈ ATMEL ◈ ST ◈ MICROCHIP ◈ NXP New List Item 2PCS of 20dbm RF Module RF-TTL-100 SMA external antenna electronic free ship USD 37.99 USB Host Shield Google Android ADK Compatible Mega 2560 1280 UNO 328 Duemilanove USD 15.99 PK11 2PCS RF-2423P 2Mbps 0dBm 2.4GHz RF Module transceiver with DIP-8 connector USD 6.99 MassDuino low cost Arduino Compatible Robot development kit for Mass production USD 45.99 2Pcs of 10dbm RF Module RF-1101D-TH+CC1101 Spring antenna 16mA electronic USD 15.99 2Pcs of 20dBm 2.4G RF Module nRF24L01+ RF-1001DP3 ext SMA ant 1Km long distance USD 19.88 5pcs 3.3V 200mA Output 0.8V DC/DC Step up Module Boost AA Battery Power PM-1033 USD 14.99 Ethernet W5100 R3 for Arduino Network expansion board support MEGA New version USD 10.99 2PCS of 16dbm RF Module RF-TTL-40-TH +AX5043 chip Spring antenna electronic USD 39.99 2PCS of 10dbm RF Module RF-1101S+CC1101 Spring antenna 16mA electronic FREE SHIP USD 15.66 2Pcs of 0dBm 2.4G RF Module nRF24L01+ RF-1001D onboard Antenna Long distance USD 10.99 2Pcs of 10dbm RF Module RF-1101D-SMA+CC1101 SMA external antenna 16mA electronic USD 15.99 2PCS of 433MHz 100mW RF Module RF-4463TH +SI4463-B1B Spring antenna electronic USD 17.99 3.3V 200mA Output 0.8V DC/DC Step up Module Boost Mode AAA Battery Power PM-1033 USD 3.99 2PCS of 12.5dbm RF Module RF-1212D-+SX1212 SMA external antenna electronic USD 19.99 2PCS of 433MHz 12.5dbm RF Module RF-1212D-TH+SX1212 Springl antenna electronic USD 18.99 5pcs Wireless Serial 4 Pin Bluetooth RF Transceiver Module HC-06 for arduino USD 37.99 2-CH DC Motor H bridge driver for Smart Car Robot for Arduino Fuse Current Sense USD 4.99 2Pcs of 0dBm 2.4G RF Module nRF24L01+ RF-1001SMA ext SMA antenna USD 10.99 2Pcs of 20dBm 2.4G RF Module nRF24L01+ RF-1001DP4 onboard ant 1Km long distance USD 19.55 2Pcs of 2.4G RF Module nRF24L01+ RF-1001S onboard antenna USD 11.99 Arduino UNO Smart Car Connector Module Wireless Upload Sketch support USD 2.99 CB-LC-2000 with LC-2000PA-P2P UC-2102 PC to PC Wireless Communication 2.4G RF USD 20.99 Wireless Serial 4 Pin Bluetooth RF Transceiver Module HC-06 Master for Arduino USD 9.99 Picture Hot Item MassDuino low cost Arduino Compatible Robot development kit for Mass production USD 45.99 10pcs Nano MD-328D Massduino Arduino Nano Lite and 1pcs CH-340G USB2Serial Cable USD 19.99 2-CH DC Motor H bridge driver for Smart Car Robot for Arduino Fuse Current Sense USD 4.99 Arduino UNO Smart Car Connector Module Wireless Upload Sketch support USD 2.99 Help & Info Add to favorite seller View Feedback Ask seller a question Visit our store About Us QR Code 10pcs Massduino Arduino Nano V3.0 MD-328D Micro USB 5V 3.3V Selectable 16MHz UNO MassDuino Nano Lower Price Micro USB Connector CH-340 USB to UART chip Arduino IDE Support Highly compatible to Arduino Nano 3.0 32KB Flash 2KB RAM 10/12/16Bit ADC /*====================================================== analogRead() // 10bit ADC, Compatible to UNO R3 analogRead_12bits() // 12bit ADC , 130 sps analogRead_16bits() // 16bit ADC , 125 sps ======================================================*/ Chip level support (MD-328D IC Lower to 0.6USD for mass purchase,click to view) Easy for prototype development , directly use for mass production! Features MD-328D 32KB Flash 2K SRAM Onboard 5V Regulator and 3.3V LDO Standard USB2Serial interface for uploading and debugging 3.3V and 5V system power voltage selectable 100% Arduino development environment Full NANO IO supported Parameters MCU: MD-328D 32K Flash 2K SRAM 16bit ADC Working Voltage : 3.3V and 5V Selectable Input Voltage: DC 5.5 to 12V 3.3V Output Current : 300mA MAX Bootloader preprogramming : Massduino MD-328D Upload sketch and communication Download and install Arduino IDE : https://www.arduino.cc/en/Main/Software Download Massduino support package: http://www.inhaos.com/downcount.php?download_id=218 Install Massduino support package: http://www.inhaos.com/uploadfile/otherpic/UM-MASSDUINO-V3.0-EN.pdf Download USB to UART cable driver : UC-340G: http://www.inhaos.com/downcount.php?download_id=193 Write code , uploading sketch , enjoy it! Package List 10 x MassDuino Nano Payment Shipping Returns Customer Services Q&A We accept Paypal payment only. Thanks for your understanding. Payment should be completed within 4 (Four) days of auction closing. Or unpaid dispute will be filed for closing auction. We will leave a positive feedback immediately after payment is received. We appreciate a positive feedback as much as you do. If for some reason there is any issue with the purchase, please contact us prior to leaving feedback, and we will be glad to work with you to have it resolved. Ship from GuangDong China, and only to your eBay address. Please update your latest address before you check out. and please make sure to provide us with correct, precise, and detail shipping address.Once your payment is completed, pls inform us by leave ebay note if the changes are needed before we send the product. Package handling only takes 1 business day at our warehouse(excluding Sat, Sun & Holiday). Orders placed on weekend will be shipped within 2 days. If an address change is needed, you will be responsible for any fees associated in the condition that you contact us after we ship your item. We only provide tracking number for standard shipping or above. If still need a tracking number, please contact us when you place an order. For countries that are a little far away, especially South America, it is suggest that you add a tracking number for your order, in case of losing parcels. We absolutely stand behind our products. We also offer a 14 day money back guarantee should you be unhappy for any reason whatsoever. We ensure all our items are new and in excellent condition prior to shipping. In the event that you receive the item that is not to the standards above, please contact us via eBay messages. Please note that all returns must be pre-approved by LinkedTron. Unauthorized returns will not be accepted. If you need to return, please check twice to confirm the item not work and contact our customer service representative, let us know the detailed problem and send us some pictures for confirmation. We reserve the right to refuse any returns for objective reasons 1. All inquiries will be replied in 24-48 working hours. 2. Our aim is 100% customer satisfaction! WE GUARANTEE BUYER WILL RECEIVE ITEM THEY ORDERED OR THEIR MONEY BACK. Please contact us with topic “Send/Ask seller a question” 3. If item not receive within estimate delivery date or item not as describe, we will refund with NO QUESTION ASK. Q: Item not received or item received not as describe? A: FULL refund or resend with no question ask. We guarantee buyer will receive item they ordered within estimate delivery date or their money back. Q: How do I pay for my purchase? A: We only accepts the payment method Paypal. Q: When will the item be shipped out? A: The item will be shipped within 1 business day once payment completed. Q: Where do you ship from? And how long does it take? A: The item ships from China. For US buyers, it will take 1-2 weeks to deliver; for non-US buyers, it will take 4-6 weeks to deliver. Q: Where is my tracking number? A: For international economy shipping, there is no tracking available. If you want a tracking, please choose the Standard shipping. Copyright of Momo_w20 . All rights reserved. Powered by SoldEazy
