10pcs Mini-circuits Xlf-173-dg+ Reflectionless Low Pass Filter Die Dc-17ghz

US $225.95

Morgan Hill, California, United States
Jun 20th

Open on mobile:
QR code

10pcs Mini-Circuits XLF-173-DG+ Reflectionless Low Pass Filter Die, DC-17GHz, 50 ohms ~ NEW ~ in original manufacturers packaging NOTE: these are die (dice) and not SMT packaged parts. Wirebonding and die attach methods must be used. The Big Deal • Patented design eliminates in band spurs • Pass band cut-off up to 21 GHz • Stop band up to 35 GHz • Excellent repeatability through IPD* process • Unpackaged Die Form Features • Match to 50 in the stop band, eliminates undesired reflections • Cascadable • Excellent Power handling Applications • Harmonics Rejection • Satellite • Radar • Military & Space General Description Mini-Circuits’ XLF-173-D+ reflectionless filter die employs a novel filter topology which absorbs and terminates stop band signals internally rather than reflecting them back to the source. This new capability enables unique applications for filter circuits beyond those suited to traditional approaches. Traditional filters are reflective in the stop band, sending signals back to the source at 100% of the power level. These reflections interact with neighboring components and often result in inter-modulation and other interferences. Reflectionless filters eliminate stop band reflections, allowing them to be paired with sensitive devices and used in applications that otherwise require circuits such as isolation amplifiers or attenuators.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Filter Type	Low Pass
Brand	Mini-Circuits
MPN	XLF-173-DG+
