110v Heating Mantle 1l / 1000ml For Round Bottom Flask

US $72.99

Ambala, HARYANA, India
Jul 21st

Open on mobile:
QR code

Heating Mantle 1L/1000mL 110v Size : Total Height : 6 inch Element Size : 5.5 inches Total Package weight with box : 2.1 Kg approx Description - Used for uniform heating/boiling of glass flasks - Effective heat distribution by glass fibre yarn attached to the heating cords - Auto cut off as the desired temperature is reached - Heat resistant aluminium body and powder coated paint - Suitable for heating flasks as per DIN 12347 - Provision of fuse and buffers for safe and smooth operation Technical Specifications:- Heating Temperature Range Up to 350 degrees Heating Output 60-1800W (according to the capacity) Exterior Body Aluminium Alloy Spare Mantle Glass fibre yarn Heating Element Kanthal Wire Temperature Control Energy Regulator Voltage Supply 220-230V/110V Frequency 50 Hz Operating Procedure:- - Put the flask with solvent onto the mantle. Make sure that the flask makes good contact with the yarn. - Ensure that the power knob is at OFF position - Connect the heating mantle to power source. - Switch on the energy regulator by rotating its knob. - Red indication glows which shows that the heating has started. - Fix the knob position at maximum i.e. 100. When the desired temperature is attained, reverse the regulator and red light indicator will go OFF. - Leave the regulator knob at this position. This will maintain the desired temperature. - After use keep the unit in safe place disconnected from power. Notes:- The energy regulator dial is marked 0-100. This marking does not indicate temperature. It indicates control level that is at position ‘0’ minimum power is allowed to flow and at position ‘100’ maximum power. Precautions - Keep the heating mantle in dry place and ensure that there is no spillage of the solvents on to the surface or the heating yarn. - In case of the spillage stop the operation of the unit by externally switching off the power to the unit and keep the unit to dry. Operate the unit again only when it is completely dry. - In case the unit does not work, disconnect the unit from the power source, remove the fuse and check. If the fuse is blown, always replace with fuse of the same rating for continued safety.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	SR
Heating Mantle Type	Heating Mantle
Capacity	1000 mL
MPN	Does Not Apply
UPC	Does not apply
