110v High Frequency Signal Generator 100khz-150mhz Free Shipping Rsg-17

US $1300

HK, China
Jul 2nd

Open on mobile:
QR code

General Features : . Output Frequency upto 150MHz; . 3rd Harmonic can be reached upto 450MHz; . Low distortion Internal Modulating frequency can be adjusted from 150Hz to 1.5KHz suppling AM Modulation (AM ); . AF output port works as audio generator as well; Major Specifications : . Output Frequency Range into 6 Ranges Range A : 100KHz to 300KHz Range B : 300KHz to 1,000KHz Range C : 1MHz to 3.2MHz Range D : 3MHz to 10MHz Range E : 10MHz to 35MHz Range F : 45MHz to 150MHz ( Upto 450MHz with 3rd harmonics) . Frequency Accuracy on Scale : +/- 5%; . RF Output : Min 100mV rms ( upto 35MHz unloaded ); Function:used on Radio Lab, Production Line and Teaching Purposes, Contents Description Power Requirement: AC 110/220V 50/60Hz SWITCHABLE Frequency accuracy on scale: 5% RF output: Min 100 mV rms (up to 35 MHz unloaded) Output control: 1mV to 100mV (measured from output terminal) Modulation: Amplitude modulation (AM) 30% approx. Audio output: Min 2V rms. Audio frequency: 150Hz-1.5KHz External audio input: 50Hz-20KHz at less than 1V rms input Dimension: 142(W)x233(D)x197(H)mm Weight: 7 Lbs Accessories: 1pc of power cord, 1 pc of test clip and instruction manual NOTE we don't ship the item to PO BOX address and we only ship the item to English address, so please leave us your physical English address when you pay.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	Does Not Apply
UPC	987792918662
Brand	Unbranded/Generic
