12 GHz PLL brick oscillator, WR-75, 8 dBm output, US $330 – Picture 0
12 GHz PLL brick oscillator, WR-75, 8 dBm output, US $330 – Picture 0

12 Ghz Pll Brick Oscillator, Wr-75, 8 Dbm Output

US $330

  • San Marino, California, United States
  • Nov 15th
Open on mobile:
QR code
12 GHz brick oscillator by Frequency West model MS-80X.   "Brick" contains an adjustable high-Q cavity oscillator around 2000 MHz that is phase locked to the times 20 harmonic of the internal crystal oscillator.  The internal nonovenized crystal oscillator is 100.000 MHz and the crystal is included in auction.  The multiplier block is times 6, so the output is 12 GHz.   Power output is 8 dBm at the WR-75 waveguide flange.    Requires a well-regulated  -20 VDC supply at about 0.4A.   The spectrum analyzer (at 1 MHz/div and at 100 MHz/division), cables, coax to WG adapter, and attenuator are not included in auction. This "brick" is in clean condition and phase locks easily and reliably.   Ships to USA for $9.00 via USPS Priority mail in antistatic bag and boxed.  Ships to Europe for $30.00 via USPS First Class International mail.
