12" Stroke Firgelli Automation 12vdc 35lb Force Linear Actuator W/ Limit Switch

US $172.49

Swanton, Vermont, United States
Jul 16th

Open on mobile:
QR code

Description Force: 35lbs Stroke: 12" Input voltage: 12 VDC Speed at No Load: 2"/sec (50mm/s) Gear ratio: 5:1 Built in limit switches (non moveable) IP Grade: IP54 (dust and splash proof) 10K ohm potentiometer built in with separate 3 wire harness This is the Firgelli Automation 12" Stroke 35lb Force Linear Actuator w/ Potentiometer Feedback. This actuator uses Firgelli Automations MB1 Brackets (sold separately) on both ends. Features: Built in limit switches (non moveable) 2" per second at no load 2 clevises, one at each end (uses manufacturer's MB1 brackets) 10K ohm potentiometer built in with separate 3 wire harness Aluminum case Low noise design Enhanced corrosion resistance Aluminum outer and inner tube Zinc alloy housing Powder metal gears Lubrication for longer life Small compact design Low Price MB1 brackets sold separately Specifications Input voltage: 12 VDC, 4A at full load Load capacity: 35 lbs Static load: 2 x max load capacity Speed at no load: 2"/sec (50mm/s) Feedback: 10K ohm 3 wires Potentiometer Clevis Ends: 6.3mm diameter uses MB1 brackets Screw: ACME screw Gear Ratio: 5:1 Duty Cycle: 20% Operation temperature range: -26ºC~65ºC (-15ºF~150ºF) Limit switch: Built-in (Factory Preset) Not movable IP Grade: IP54 (dust and splash proof)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Firgelli Automations
Type	Firgelli Automations
MPN	FA-PO-35-12-12
UPC	Does not apply
