1219-8404 36-48v, 600a Motor Controller

US $428.75

Morton Grove, Illinois, United States
Jun 9th

Open on mobile:
QR code

Curtis PMC 1219 motor speed controller features a microprocessor based logic section combined with a proven MOSFET power section. The 1219 controller is efficient, cost effective and easy to install. Application: The Curtis PMC 1219 controller is ideally suited for larger electric vehicle applications, such as walkie/rider pallet trucks, personnel carriers, stackers, reach trucks, fork lifts and other series or compound motor applications. Features: Compact size. • Environmental protection provided by a sealed package • Advanced high frequency power section utilizing custom power MOSFETs provides high efficiency, silent operation and reduced motor and battery losses. • Power connections made by solid copper busses with polarized Molex connector for control signals. • Thermal protection and compensation circuitry provide under temperature cutback, constant current limit over the operating range and linear rollback in over temperature. No sudden loss of power under any thermal conditions. • Over voltage and under voltage protection. • Programmable through the Curtis PMC 1307 handheld programmer, an optional universal unit which allows programming, testing, and diagnostics. • Complete diagnostics of the controller can also be accomplished with the built-in status LED. • Meets or exceeds EEC fault detection requirements with circuitry and software to detect faults in the throttle circuit, MOSFET drive circuits, MOSFET transistors, contactor drivers and contactors. • Input sequencing options include neutral start (HPD) and static return to off (SRO). • True arcless contactor switching with microprocessor controlled contactor sequencing. • Throttle position variable or fixed plugging current options. • Neutral braking option provides for automatic plug braking in neutral. • MultiMode™ option for programmable two mode (current limit, speed, acceleration) operation. • Emergency reverse function (belly button) provides full function with a single input. Additional output provides for an emergency reverse circuit continuity check. • Anti-rollback (ramp start) function gives full power for starting on ramps. • Simple contactor and switch wiring. Coil drivers are monitored for short and open circuit for fail-safe operation. • Flexible throttle circuitry accepts a variety of throttle types including: 5k-0, 0-5k, 0-5v, 0-10v and three wire potentiometer.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Curtis
Country/Region of Manufacture	United States
MPN	1219-8404
