12ch Wireless Transceiver Module And 12 Button Remote Control With Decoding

US $17.37

China, China
Jan 29th

Open on mobile:
QR code

Wireless Transceiver Module+12 Button Remote Control Description Description: RF2013-III-12 remote control receiver transmitter kit: multi-channel intelligent remote control decoder, set jog, self-locking, interlocking one. Users can now be set according to your needs. Selection of imported special decoder to decode MCU. Function can be customized according to customer requirements. Each output sink current is 10MA, pulled current 5MA. Input voltage between 3V-5V. If you want to change the 12V input is also very convenient, just add a 7805 on the line. Model: RF2013-III-12 Kit Operating voltage: 3V-5V Receiving frequency: 433M Receiver Module: superheterodyne RXB12 Remote control distance: 1Km (nominal value), but the actual should generally is between 150m-300m. According to different customers work environment is different. Control group: 12 groups Work: self-locking, jog, interlock. Remote control code: SC2262 / 4 Receiver board Size: 42 * 26mm Work instructions: Self-locking: Press one button, which outputs corresponding open, key release, the output remains open. Press the key again, the corresponding output all the way off. Jog: press one button does not release for this output should open, release the button, the output is off. Interlock: Press one button, the corresponding output open this road before all other open output fully closed, leaving only the current output by pressing the corresponding open this road. If you press this output originally opened directly off this output. Work displayed: Receiver module at power, learning indicator will be displayed according to the current work, study and blinks once said that the current work is self-locking mode, blink twice indicates that the current way of working is to jog mode, three flashes indicates that the current way of working is mutual lock mode. Working mode switching: Press and hold the front power button on the receiver module learning does not loosen, then to the receiver board is energized, then learn indicator light will blink, change the number of flashes indicates why the current module. If the original receiver module is a self-locking mode, put the module into jog mode, if the original is the point mode, put the module into an interlocking pattern, if the original is interactive mode will change the self-locking mode module, this cycle . Mode indication see above "work shows" Remote learning method: After power on the receiver module, click the button to learn loosen, then learn indicator light, press any key on the remote control, if learning is successful, the receiving plate learn indicator flashes three times quickly, then turn off. At this remote control can be operated on the receiver board. A receiver board up to learn 40 remote control. Qing code method: If you want to learn over the original remote control can not control receiver module, press the release button to learn not wait until learning indicator light, then learn indicator light will flash slowly three times. Said the success of the Qing code. Package listing: 1PCS 12CH Wireless Transceiver Module And 12 Button Remote Control With Decoding Payment 1.We accept Paypal only. 2.Please confirm your ebay shipping address is exact after payment. 3.If your purchased is more than £30.00, please offer your phone number with shipping address. Delivery details 1.All item will be shipped by Airmail post within 1 business days. It takes approximately 15-25 days (USA ,CA,AU,UK,DE).other country 15-35 days. 2.Express by EMS ,it must add 25 USD shipping fee, it takes 5-10 workdays for delivery.If you need other Epxress(DHL,Fedex.UPS etc.),please contact us to talk about shipping fee. 3.Once you purchase, please DONOT leave negative, neutral feedback or open any case if you have not received item in 30 days, because we have mentioned the shipping time repeatedly. Contact us ???? 2 1.We offer retail and wholesale services. We can provide products in accordance with your requirements. If you have any questions or something to consult, please send us ebay message. 2.All messages will be answered within 1 business day. If you do not receive our reply, please kindly re-sent your message and we will reply to you as soon as possible. 3.Our aim is to provide Top Level Customer Service, Business hours are 9am to 6pm Beijing time (+8 GMT), Monday to Friday. Engineered for professional eBay sellers!
