12mm Rotary Encoder Switch Flat-top Knob New

US $470

Shanghai, China
Jan 29th

Open on mobile:
QR code

12mm Rotary Encoder Switch Flat-Top Knob NEW 6x Snap-in Rocker Switches Pack of 10 Latching OFF-ON N / O Push Button Switc... 2X White LED Light Windscreen Washer Water Jets 12... Brand new 12mm rotary switch for encoders. Knob is flat-top with groove lines. See pictures. Specifications: Weight: 11g Electrical Output: 2-bit gray code Closed Circuit Resistance: 3 ohms Contact Rating: 1 mA at 5 VDC Insulation Resistance: 10 megohms at 250 VDC Dielectric Withstanding Voltage Sea Level: 50 VAC minimum Electrical Travel: Continuous Contact Bounce (15 RPM): 5.0 ms. RPM (Operating): 100 Mechanical Angle: 360° continuous Running Torque: 30.6 to 204 g-cm (0.42 to 2.83 oz.-in.) Shaft Side Load (Static): 2.04 kgf (4.5 lbs.) minimum Weight: 3 gm (0.1 oz.) max Operating Temperature Range: -30 °C to +70 °C (-22 °F to +158 °F) Storage Temperature Range: -40 °C to +85 °C (-40 °F to +185 °F) Humidity: MIL-STD-202, Method 103B, Condition B Vibration: 30 G Contact Bounce: 10~55~10 Hz / 1 min. / Amplitude 1.5 mm Shock: 100 G Rotational Life: 30,000 cycles minimum Switch Life: 20,000 cycles minimum IP Rating: IP 40 Wave Soldering: Sn95.5/Ag2.8/Cu0.7 solder with no-clean flux: 260 °C max. for 3-5 seconds Hand Soldering is NOT recommended Power Rating (Resistive Load): 10 mA at 5 V DC Switch Travel: 0.5 +0.4/-0.3 mm Switch Actuation Force: 360 +153/-102 gf (5 +2.1/-1.4 oz.-in.) ? We only accept paypal payments ? When we receive your payment, we will be help you arrange shipping in 2 working days. (Weekends and holidays do not break) ? All our parcels are shipped via China Post.Can provide Following two Delivery mode: Airmail It takes about 15-25 days EMS (Express Mail Service): It takes about 7-14 days ? Buyer should expect to pay any amount charged by the government of bidder's country; this includes but not limited to duty & tax ? Shipping & handling fees are non-refundable. ? If you haven’t received the item in one month, we will refund to you.(PLEASE INSPECT YOUR ITEMS WHEN THEY ARE RECEIVED) ? Once you receiving the item with satisfaction, please leave us positive feedback, and 5 STAR DSR. Thank you! ? Once you Feel dissatisfied with the projects received,please first and us use E - mail contact and communication,Do not very direct and impulsive give a Neutral or Negativ!Because the Neutral and Negativ can not solve any problems! Thanks! eBay Cross Border Trade powered by MerchantRun GlobalLink
