12v 24v 48v 12-50v 15a 600w Dc Motor Speed Control Pwm Mach3 Usb Cnc Plc

US $4403

Guangzhou , China
May 28th

Open on mobile:
QR code

12V 24V 48V 12-50V 15A 600W DC Motor Speed Control PWM MACH3 USB CNC PLC DESCRIPTION Features: 1. Power input DC: 12-50V. only supports DC input. There are reverse power protection. 2.Can support motors of different parameters after adjust. Adjust OC-ADJ-T match for potentiometer. The maximum current of 20A,but we recommend not over 15A.The factory located at 2A 3.Independently controlled motors in the manual, you can control PWM base frequency of the motor via jumper ,setting to match different motor noise at different speeds to a minimum. 4.There are two control modes: controlled by jumper switch is independent manual control motor or external PWM signal, a PLC access or control card to control the motor. External PWM input requirements: level 3.5-12V VPP, frequency 1K-5KHZ ,. duty cycle of 0% -93%. 5 with alarm output function. When motor stall, you can send a signal to the control card or PLC, or PLC control card do let down, and other related actions. 6.With power indicator, stall / overcurrent warning indicator function. 7.independent manual potentiometer can be adjusted accordingly on the governor to control the motor speed control motor. 8. Internal resistance of 330 ohm resistor, when connected PLC,to series with a 1.5-2.7K ohm resistor. Then MACH3 and other 5V level motion control card can be connect directly. 9 Alarm output interface specification: maximum drive current 12MA as MACH3 interface cards:. NPN-E port access GND. NPN-C port access P10 (or other input ports can) Interface define: 1) GND: 12-50VDC Power Negative 2) 12-50V: 12-50VDC power being 3) M + M-: DC motor . 4) PWM +: positive terminal of an external PWM signal, MACH3 positive terminal of PWM controller, PLC negative terminal of PWM 5) PWM-: negative terminal of an external PWM signal, MACH3 negative terminal of PWM controller, PWM PLC to the negative terminal 6) NPN-E: NPN output alarm transmitter pole. Pick MACH3 board GND 7) NPN-C: NPN output alarm set motor pole. Pick MACH3 plate P10 and other inputs 8) OC-ADJ-T: machine over current point setting potentiometer. A letter in 2A, the maximum is set to 20A. PAYMENT We Only Accept Paypal on Ebay. For specific requirements, please feel free to contact us. SHIPPING Shipping: Packages are sent from overseas, please expect lengthy custom delays if you choose to use default shipping service. Shipping to some countries is slow. That depends on your local postal service. Most orders to USA take about 7-20 days using epacket(USPS first-class service with tracking#). Shipping to most other countries takes about 10-30 days via Economy Int'l Airmail without tracking#. In rare case, it can take up to 40 days. It depends on your location and local postal service(e.g., Russian Postal service is slow), as well as the weather condition along the shipping. We don't take responsibility if you submit wrong address. Here's an approx delivery time to some countries: Please contact us if you need a tracking# or express shipping service. TERMS OF SALE If you are facing with troubles below, please contact us as soon as you can Defective or Wrong: full refund or send you a new replacement Missing: new package arranged, or partial refund Dislike: full refund after we received your item (buyer undertakes return shipping fee) ABOUT US Our working time is 08:30-17:30 from Monday to Friday in Beijing Time. Because of the time difference, we may not reply your email immediately. All emails will be replied in 24 hours, please understand that. We devote to making the best service for you. We look forward to serving you. Any questions, please contact us via our ebay email. Your emails are warmly welcomed. CONTACT US Consumers' satisfaction is our first priority and pursuit . We promise to solve your problem in a good way . We consider neutral and negative feedbacks as a SHAME. So please never give us a neutral or negative feedback before communicating with us .
