12V to 24V 20A Step Up Power Voltage Converter Boost Regulator Non-Isolated, US $54.88 – Picture 0
12V to 24V 20A Step Up Power Voltage Converter Boost Regulator Non-Isolated, US $54.88 – Picture 0

12v To 24v 20a Step Up Power Voltage Converter Boost Regulator Non-isolated

US $54.88

  • Phoenix, AZ, United States
  • Jul 12th
Open on mobile:
QR code
12V to 24V 20A Step Up Power Voltage Converter Boost Regulator Non-Isolated Wiring: INPUT+ to BAT+, INPUT- to BAT-, OUTPUT+ to LOAD+, OUTPUT- to LOAD-Reminder: Never reverse the polarity. Use the enough big cable to avoid the voltage drop. Never connect to solar panel or wind turbine. Never charge the battery. Keep good air convection. Daygreen P/N: A1U2420 Efficiency: 96% Input Voltage: 11-16VDC Output Voltage: 24VDC Output Current: 20A Ripple: 200mVp Line Regulation: ±0.2% Load Regulation: ±0.2% Voltage Accuracy: ±1.5% Enclosures: IP68 Dimension: 100*113*35mm Net Weight: 0.65kg Case Operating Temperature: -40~85°C Certificates: CE Rohs Warranty: 3years MTBF: 100,000 hours Application: 12VDC battery of vehicles as input power to 24V-28VDC appliances as output load. Questions How to choose the correct current for loads? For example, if the max current of your load device is 10A, then choose 10A/0.8=12.5A at least for resistive loads according to international standard. If the load device is motor or compressor, then you may choose 10A/0.5=20A according to real testing result since the motor and compressor starting current may be 2-3 times than nominal current. 100% full rated power and stable output voltage 100% burn-in test and 4 times quality inspection Over current protection, Over voltage protection, Over temperature shutdown, Fuse built Aluminium shell with epoxy potting and waterproof IP68 High efficiency up to 97%
Condition:
New – Open box: An item in excellent, new condition with no functional defects. The item may be missing original packaging and may have been used for testing or demo purposes. The item includes accessories found with the original product and may include a warranty. See the seller's listing for full details and description. ...
Size 12V TO 24V 20A 480W Plus
Model Does not apply
MPN Does not apply
Brand Daygreen
UPC 634769631948
ISBN 0634769631948
EAN Does not apply
