16 Outputs Module For Microcontrollers With Spi And Arduindo

US $15.00

Tampa, Florida, United States
Jan 29th

Open on mobile:
QR code

This is a 16 Output High Side Switch module capable of handling Inductive Loads. It will work with any microcontroller that features SPI interface. Arduino boards are based on ATmega microcontrollers and most Atmel AVR series features serial SPI interface. Writing and reading SPI is very easy and fast. Most of the I/O pins on any microcontroller are limited to mA push/pull currents with an additional limit of total power per IC. In case you want to control higher current devices you may need to use this module The OEX16V285 has 16 DMOS outputs suitable for inductive and resistive loads. No problem with relay's high inductive coil, DC motor, selonoids, incandescent lamps...etc. Data is transmitted serially using SPI protocol. Works with any microcontroller/microprocessor. If your uC does not have SPI you can dedicate 5 I/O pins and create your own SPI in the software. Output voltage up to 40Vdc. Each output can deliver continuously up to 750mA. Output short circuit protection, Current limit circuitry, Internal clamping for inductive loads. Serial diagnostic output for overload and short circuit protection allows you to monitor status of devices connected to it. Board size only 2.15"x2.25". Here is the simplified data sheet of OEX16V285 in pdf format OEX16V285.pdf This module is based on two L9822 connected in series. Here is the link to L9822 Data Sheet. L9822.pdf This auction is for 1 (one) module only. We don't supply mounting screws. If you need stepper motor please check our other auction. We have Nema 17 and Nema 23 motors on sale now! We have also brackets for Nema 17 and 23 motors in stock. Please check our other auction for MPBR-17RA and MBPR-23RA. Please, check our eBay store for stepper motors, drivers and power supplies: http://stores.shop.ebay.com/Stepper-Source INTERNATIONAL BUYERS! Please send email with request to calculate shipping cost. We ship to overseas destinations via USPS International Priority Mail but if you wish to select other method please let us know and we'll give you the exact cost. NOTICE: Buyers with feedback score (5) or less please do NOT bid/purchase without contacting us first. Any such transaction will NOT be accepted. PLEASE CONTACT US FIRST! ANY QUESTION: Send email to mirekwind@att.net On Jun-08-11 at 05:03:35 PDT, seller added the following information: Use the FREE Counters 1 million sellers do - Vendio!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	OEX16V285
Country of Manufacture	United States
