16" Precision Horizontal And Vertical Rotary Table

US $749.00

  • Duluth, Georgia, United States
  • Jan 30th
Item No. 317 - 0916 Shipping weight: 399 lbs Truck shipping only We offer the low shipping rate, please contact  topqc789@aol.com or  678-232-7327 The dimension of the package: 45 x 27 x 12" Specifications: Diameter of table: 15.748" ( 400 mm ) Morse taper center hole: MT4 Diameter of center hole: 1.5748" x 0.3937" Width of T slot: 0.5511" 6 T slots Width of locating key: 0.7086" Transmission ratio of worm gear: 1:90 Readout of hand wheel: 1' per graduation Minimum value of vernier: 10" Indexing accuracy: 60" Maximum working load: 661 lbs ( horizontally ) Maximum working load: 330 lbs ( vertically ) Surface to center slot squareness 0.0003" Taper center bore concentricity TIR 0.0005" Surface to base parallelism 0.0008" Surface to angle face squareness 0.0004" Center bore concentricity TIR 0.0008" Maximum spacing error 16" ....... 45 seconds 10 second vernier reading Dividing Plate is an optional parts and see another listing on Ebay. Warranty: one year. TSL400 = 16"   Call Send SMS Add to Skype You'll need Skype CreditFree via Skype Powered by ProStores
