1602 Character Lcd Keypad Shield 16 X 2 Input/output Expansion Board For Arduino

US $4.99

  • ShenZhen, China
  • Jun 9th
Open on mobile:
QR code
Product Description LCD Keypad shields input/output extended use 2 lines 16 characters LCD panel, with contrast adjustment and backlight, use a simulated input of mouth, completing five buttons, a reset button, the unused IO mouth extend out spare, make full use of I/o port.Take up the digital port: PIN4 (db3), 5 (DB5), 6 (DB6), 7 (DB7), 8 (RS), 9 (E), 10 (backlight control), A0 simulate keystrokes port.(LCD color is not specified, random delivery.) Cooperate with the Arduino using: Module debugging: Will LCD Keypad shields inserted to the Arduino controller, then need to download the LCD4Bit_mod. H (right click save as) library files to the Arduino - 0015 \ hardware \ libraries, then compile the following a test program to download to the Arduino, first use the LCD Keypad shields, did observe LCD display character first, if there is no contrast shows characters that may be incorrect, you can use a word screwdriver adjustment RP1 (clockwise), characters can be transferred to appear clearly. Package Included: 1 x 1602 Character LCD Keypad Shield 16 X 2 Input/output Expansion Board For Arduino Payment 1. Accept paypal. 2. All major credit cards are accepted through secure payment processor paypal. Delivery details 1. Any shipment problem, please feel free to contact us first. we would try our best to help you. 2. It's better to leave phone number when you order,maybe custom would call you when dispatch your package. Terms of sales 1. Custom duty was not included in item price, pleaes understand. About US 1. Choosing qunqi Feels Fantacy 2. We are the owner of patent and trademark of qunqi Contact us 1. Working time:Monday to Saturday 2. We would response you within 24 hours on working time. On Sep-09-15 at 19:48:05 PDT, seller added the following information:
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Country/Region of Manufacture China
UPC 710824703055
