1602 Display Black Character LCD Module 16x2 Controller Yellow Green Backlight, US $2.99 – Picture 0

1602 Display Black Character LCD Module 16x2 Controller Yellow Green Backlight, US $2.99 – Picture 1

1602 Display Black Character Lcd Module 16x2 Controller Yellow Green Backlight

US $2.99

shenzhen,Guangdong, China
Jun 9th

Open on mobile:
QR code

1602 Display Black Character LCD Module 16x2 Controller Yellow Green Backlight Description: Yellow Green-Back black word Standard 16X2 character LCD module (backlight / Yellow-Green ) 1602 with standard 16 pin connector, including: Pin 1: VSS is in power Pin 2: VDD 5V positive power supply connection Pin 3: V0 LCD contrast adjustment for the client, then the contrast is the weakest power, ground power the highest contrast, the contrast is too high will have a "ghosting", when used with a 10K potentiometer to adjust contrast Pin 4: RS for the register selection, the selection of data register high, low, select the instruction register. Pin 5: R / W to read and write signal lines, when high read, low write. When the RS and RW can be written together for the low level command or display the address, when RS is high, low RW can be read busy signal, when RS is low for the high RW can write data. Pin 6: E side to side to make, when E Duanyou high jump into a low, the LCD module execute the command. Pin 7 to 14: D0 ~ D7 for the 8-bit bidirectional data line. Pin 15 feet: Backlight positive supply Pin 16 feet: Backlight negative supply Country Delivery time working day (no holiday) 8-10 11-15 16-22 23-30 >31 >45 USA 40% 50% 9% 1% Refund Refund UK 1% 10% 64% 25% Refund Refund Australia 1% 15% 50% 34% Refund Refund Canada 0.05% 5% 20% 75% Refund Refund Spain/Italy 0.05% 1% 5% 70% 20% Refund Europe 0.05% 5% 20% 60% 15% Refund Russia 0.05% 1% 5% 50% 25% Refund other coutries 0.05% 1% 15% 60% 20% Refund Shipping Terms : -Items will be shipped by Singapore Post within 1-2 days after payment confirmation. -Please contact us if you have any prefer express , we will quote you exact cost. -International buyer is responsible for any applicable import duty & local taxes. Please verify with your customs before purchase. -Please contact us as soon as possible if you haven't received the parcel after 30 days. Packing Condition : 1. All items are 100% brand new 2. All the items will be checked & tested all functions before posting to you. 3. "Shipping Notice" will be sent to buyer after item shipped by email. Product Warranty: 1.All our products comes with 90 days warranty. Please advise us within 14 days after received the item and found function defect. 2.Buyer need to return the item for the replacement on his own cost. Item returned is with original packing condition by register mail and we will replace the new one to you immediately or refund you. 3.Shipping and handling charges are non-refundable at any case. Feedback : Postive feedback is much more important to our sellers,so please leave us positive feedback when you are satisfied with us. Please contact us if you have any discontent about our items. We will find a way to solve all problems Contact us : If you have any questions,please feel free to contact us,we will reply within 24 hours in the working days. Thank you for looking our listing and enjoy shopping.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	NO
MPN	LCD Module
UPC	Does not apply
