1700°c 16x12x12" Lab Controlled Atmosphere Muffle Box Melting Heating Furnace

US $24,990.00

Livingston, New Jersey, United States
Jan 30th

Open on mobile:
QR code

GCF1700 series controlled atmosphere furnaces feature a chamber with alumina fiber insulation and MoSi2 heating elements. A double walled steel internal housing helps minimize heat loss to exterior surface. Furnace operation is controlled by Shimaden 40-segment digital controller with built-in RS485 digital communications port and USB adaptor, allowing the user to connect to a PC for remote control and monitoring of the furnace. You can also save or export test results. All our furnaces are CE compliant. The Benefits of an Atmosphere Furnace An atmosphere furnace provides the perfect environment for various procedures in many laboratories, providing the controlled temperature and atmosphere specific projects require. The controlled atmosphere is desired to complete tasks that require exact temperatures with no room for error. This is the best way to ensure the successful outcome of your project because it is sealed tightly to ensure the proper environment. Gases One of the main components of the atmosphere furnace is the correct mixture of gases. The precise measurement of each gas is essential to the success of your project. You can use a separate chamber to mix the gases, which are then pumped into the furnace chamber where the work will be completed when they are done mixing. It is essential that the separate chamber that holds the gases does not receive any outside air because it could throw off the gas mixture and render your project useless. Temperature Proper temperature control is vital to the success of your project as well. Temperatures that are too high or too low will cause problems with the process and could cost your company a significant amount of money. Across International furnaces come with built-in 28-segment PID digital temperature controller for accurate monitoring and consistency. Features Multiple gas inlets and outlets with stainless steel ball valves. Flow meter to control inbound and outbound gas flows. Outlets can be ignited to burn off gas. Furnace chamber is welded and oil leak tested to ensure air tightness. Furnace door is sealed with high temperature silicon gasket. Built-in stainless steel water-cooling panel protects door sealing gasket when furnace is under heavy use. Microprocessor based self-tuning PID control provides optimum thermal process with minimal overshoot. Multiple atmosphere processes in a single cycle are possible (ex: binder burn out in air and parts sintering under rough vacuum or inert gas environment.) Built-in ammeter and dual voltmeters for easy monitoring and troubleshooting. Built-in computer interface. Long life type B thermocouple. Built-in swivel casters for portability. Safety switch turns off furnace when door is open accidentally Safety Overheat protection shuts down the furnace if temperature is outside of acceptable range (refer to controller's manual) or when the thermocouple is broken or malfunctions. Power failure protection resumes furnace operation right after the point of failure when power is reestablished. Specifications Chamber dimensions 16 x 12 x 12" (D x W x H) Electrical requirements 208-240v, 50/60Hz, single phase, 13kW 60A Heating element Molybdenum silicide (MoSi2, diameter 7mm) Maximum/Constant temperature 1700°C/1600°C (Depends on gas environment) Oxygen level Up to 100ppm (0.01%) Temperature controller Shimaden fp93 (made in Japan) with 4 programs and 40 segments (ie. 4 x 10 segments or 2 x 20 segments). Maximum heating rate 15°C / min Furnace cavity morgan polycrystalline 95% alumina fiber Thermocouple type B Temperature controller precision +/- 1°C Vacuum level 0.75 Torr (100 Pa) Gas inlet/outlet 1/4" hose barb with 1/4" BSPT (British Standard Pipe Thread) Unit / Shipping dimensions 33 x 28 x 62" / 41 x 35 x 71" (D x W x H) Unit/shipping weight 900/1050 Lb CE compliance Yes Maximum temperatures Air, Nitrogen Dioxide (NO2), Carbon Dioxide (CO2) 1700°C Helium (He), Neon (Ne), Argon (Ar) 1650°C Sulfur Dioxide (SO2) 1600°C Nitrogen (N2), Carbon Monoxide (CO) 1500°C Wet Hydrogen (H2) 1400°C Dry Hydrogen (H2) 1350°C How to program Across International furnace controller Standard package Part description Quantity Part image GCF1700 controlled atmosphere furnace 1 pc Type B thermocouple 1 pc Flow meter 1 pc Alumina cushion block 1 pc Furnace door block 1 pc Stainless steel tongs 1 pc Thermal gloves 1 pair High temperature Al2O3 alumina crucible 5 pcs Spare fuse 2 pcs USB computer interface kit 1 set Water pump 1 pc Furnace operation manual 1 pc Shimaden fp93 temperature controller manual & software 1 pc

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Across International
Model	GCF1700.16.12.12
