1700°c 6x6x6" Lab Benchtop Digital Box Muffle Chamber Melting Heating Furnace

US $6,790.00

Livingston, New Jersey, United States
Jan 30th

Open on mobile:
QR code

This listing is for one brand new CF1700 1700°C muffle furnace (chamber size: 6 x 6 x 6"). CF1700 series muffle furnaces feature a chamber with alumina fiber insulation and molybdenum silicide (MoSi2) heating elements. A double walled steel internal housing helps minimize heat loss to exterior surface. Furnace operation is controlled by Shimaden 40-segment digital controller with built-in RS485 digital communications port and USB adaptor, allowing the user to connect to a PC for remote control and monitoring of the furnace. You can also save or export test results. Features Microprocessor based self-tuning PID control provides optimum thermal process with minimal overshoot. Built-in ammeter and dual voltmeters for easy monitoring and troubleshooting. Built-in computer interface. Long life type B thermocouple. CE compliant Safety Overheat protection shuts down the furnace if temperature is outside of acceptable range (refer to controller's manual) or when the thermocouple is broken or malfunctions. Power failure protection resumes furnace operation right after the point of failure when power is reestablished. Specifications Chamber size (DxWxH) 6 x 6 x 6" Max. working temperature 1700°C (3092°F) Refractory lining 1600 grade fiber alumina Heating element Molybdenum Silicide (MoSi2) Thermocouple type B Constant working temperature 0 - 1600°C (0 - 2912°F) Temperature controller Shimaden fp93 (made in Japan) with 4 programs and 40 segments (ie. 4 x 10 segments or 2 x 20 segments) Max heating / cooling rate < 15°C (59°F) / min Temperature accuracy +/- 1°C Input 208-240v AC, 50/60Hz, single phase Output Max. 5KW Furnace dimensions (WxDxH) 22 x 21 x 34" Unit weight 400 Lb Shipping dimensions (may vary) 30 x 29 x 42" CE compliance Yes How to program Across International furnace controller Standard package Part description Quantity Part image CF1700 muffle furnace 1 pc Type B thermocouple 1 pc Stainless steel tongs 1 pc Spare heating element 2 pcs Alumina thermal cushion block 1 pc Thermal gloves 1 pair High temperature Al2O3 alumina crucible 5 pcs Spare fuse 2 pcs USB/RS485 computer interface kit 1 set Furnace operation manual 1 pc Shimaden fp93 temperature controller manual & software 1 pc

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Across International
Model	CF1700.6.6.6
