1hz-150khz Pwm Pulse Frequency Duty Adjustable Cycle Module Signal Generator

US $15.99

Causeway Bay, Hong Kong
Jun 18th

Open on mobile:
QR code

Signal Generator PWM Pulse Frequency Duty Cycle Adjustable Module With LCD Display and Case 1Hz-150Khz 3.3V-30V Description: Features: - Support Serial operation - Wide frequency range,high precision - LCD can display frequency and duty datio,Easy to oprate - Output of three-channel PWM at the same time - Adjustable Frequency,3-channel frequency output consistent,duty ratio can be independently adjusted,suitable for most occasions Specifications: 1.Operating voltage3.3~30V; 2. Frequency range1Hz~150KHz; 3. Frequency accuracy:In each range of accuracy is about 2% 4. Signal load capacity:Output current can be around 5~30ma 5. Output amplitude: PWM amplitude and supply voltage equal 6. Ambient temperature:-20~+70° 7. Size:5.5x3.8cm/2.17x1.50inch Overview: 1. Module has 4 independent keys,used to set the frequency and duty ratio,support short press (increase or decrease a unit) and long press (fast increase or decrease),very simple,set the parameters automatically save,power loss. 2. 3-Way duty ratio button can be pressed at the same time,real-time adjustment, liquid crystal display is the last pressed button duty ratio,real-time is very strong,can be used as a simple several road duty ratio scan. Parameter Settings: Three-channel PWM is outputted,wide frequency range and the duty ratio can be adjusted independently Frequency is divided into four areas,automatic switching: 1.XXX(No decimal point): 1HZ Stepping Unit,Range:1Hz~999Hz; 2.X.XX(The decimal is in hundreds place):0.01KHZ Stepping Unit,Range: 1.00Khz~9.99Khz; 3.X.XX(The decimal is in the tens place):0.1KHZ Stepping Unit,Range: 10.0Khz~99.9Khz; 4.X.X.X(The decimal is in the ones place):1KHZ Stepping Unit,Range: 1Khz~150Khz; e.g. ,frequency display:100 represent the pulse of 100Hz ; 1.01 represent the pulse of 1.01KHz; 54.1 represent the pulse of 54.1KHz 1.2.4 represent the pulse of 124Hz The value range of dutyfactor: 0~100%,100% is represented by A0%. All parameters setted up can be automatically saved in case of power cut. Application: 1.Used as square wave signal generator to generate square wave signal for experiment development and use 2.Used to generate a square wave signal to control the motor driver; 3.Generating adjustable pulses for MCU use; 4.Generate adjustable pulse, control related circuit (PWM dimming speed and other applications). UART Serial Command: Baud rate:9600 bps Data length:8 Stop bits:1 Check digit:none Flow control:none 1.set the frequency of the PWM “F101”: Set frequency of 101 HZ (001~999) “F1.05”: Set frequency of 1.05 KHZ(1.00~9.99) “F10.5”: Set frequency of 10.5KHZ(10.0~99.9) “F1.0.5”:Set frequency of 105KHZ(1.0.0~1.5.0) 2.set the duty ratio of PWM "DX:YYY": Set PWM duty ratio x: (1~3) PWM serial number,YYY: (000~100) duty ratio; For example d1:050,set 1th PWM duty ratio to 50% 3.Read Setup parameters Send a "read" string to read the parameters of the setting. Message format:F156,D1:052,D2:059,D3:058, Set successful return:DOWN Set failed to return:FALL Package Includes: 1x Signal Generator With LCD Display and Case Shipping The orders are shipped 1-2 business days after receiving the payment. Depending on the location of the customer, we use different shipping methods. We ship worldwide, Except some countries. Estimated dates of delivery is bellow: Country appox. Delivery Time 7-21 Business Days United States United Kingdom 7-25 Business Days Australia 10-27 Business Days Europe 7-25 Business Days Canada 10-27 Business Days Worldwide (other countries) 10-30 Business Days We also offer other (EXPRESS) shipping methods for some items, such as: EMS Experss, DHL, FedEx, etc... For more info about other shipping methods, please contact us for more detail. Customs: Buyers are responsible for import duties, custom fees and taxes, if any. Please check with your country custom office to determine the additional costs impose on the item prior to buying. Payments We accept PayPal Only You can leave notees (for example: item color, size etc...) in PayPal when making the payment if you have any special requests. du im angin qarnes, es gtelem im Refunds & Returns We offer 30 days return policy. Please contact us within 30 days from the date you receive your order if you have any issues with the product and would like to return. Only unused, undamaged and item in its original condition can be qualified for a return. If the package arrives in a damaged condition, please record the issue immediately with the courier or delivery company. You should also take photos of the box that contains the product, take photos of the whole content of the package you received, take photos of the damaged and/or broken parts of the items you received. All the photos must be of good quality and clearly show the broken/damaged parts. All returned items MUST BE in the original packaging and you must provide us with the shipping tracking number, specific reason for the return. We will refund YOUR FULL WINNING BID AMOUNT, upon receipt of the item in its original condition and packaging with all components and accessories included, AFTER BOTH Buyer and Seller cancel the transaction from eBay. OR, you may choose to have a replacement . If you are not satisfied with the product you received and want to return it, you have to submit the photos of the shipping label on the package, the photos of the whole content of the package and the photos of the problem you have with the item. If the problem cannot be depicted on photos, please take a short video, upload it to youtube and give us a link. Once this information is submitted, we will work out a good solution which will satisfy you. Please contact us to get a reference number and return address BEFORE sending out your return. Goods without reference number will NOT be accepted. Please write the reference number on/in the returning package. Buyer is responsible for return shipping cost. Feedback Your satisfaction is our highest priority! We work hard for it. Do not hesitate to contact us if you have any question before or after the purchase. We will be happy to respond you within 24 hours and assist you in short time. If you are not satisfied with the order, please contact us we will resolve the problem in very short time. Please, do not rush to open a dispute or leave bad feedback, Remember that we can kindly solve any problem in short time. This is much faster and more convenient. Remember: we respect all our customers Thank you! We appreciate your cooperation and time! We sincerely appreciate you interest in our products! Please check our eBay store for more great offers at: vst-store

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country/Region of Manufacture	China
Brand	Unbranded
MPN	Does Not Apply
UPC	Does not apply
