1p New Best Arm Emulator Arm7 Arm9 Arm11 Cortex-m3 J Link V8 Ads Iar Stm32 Jtag

C $12.04

China, China
Jan 29th

Open on mobile:
QR code

1P NEW BEST ARM Emulator ARM7 ARM9 ARM11 Cortex-M3 J link V8 ADS IAR STM32 JTAG J-link Jlink V8 ARM Emulator supports ARM7 ARM9 ARM11 Cortex-M3 core ADS IAR STM32 Emulator JTAG interface TVS+FUSE Protection V8.0 V7.0 version of the improved version of the relative: 1. Improving the SWD interface circuit, the use of counterfeit JLINK V8 JTAG debug mode can be normal when debugging CORTEX-M3 core chips will not use SWD functionality V7 hardware SWD part with the V8 not the same, if forced to switch to SWD mode, JLINK the main chip will be destroyed! JLINK V8 interface circuit using two-level converter chip, using a level converter chip will be fake V8! 2. V8.0 using two-color LED can indicate more work status, V7.0 only an LED indicator light 3. To optimize the firmware structure and function of the firmware upgrade boot loader area to move to double the size of the application area Easy to add new features; 4. Support for ARM11 better and faster than JLINK V7, is the first choice for ARM11. Other differences: 1. J-Link V8 use AT91SAM7S64, expanding the capacity of Flash and SRAM to facilitate future upgrades; 2. J-Link V8 improves the SWD interface, an increase of driver chips, (V6 and V7 in the SWD is a direct quote from the pin to the target CPU board); 3. J-Link V8 SWD improved control methods, V7 is the I / O direct-drive, V8 with a special method, there is not effective anyway V8's SWD velocities slower than the V7 4. J-LinkV8 have three lights, one directed USB Communications, a direct target CPU, reset state, a direct 5V output is turned on V7 only 1 USB communication indicator 5. J-Link V8's firmware update process is not DLL, and cannot write the same as V7 Boot loader on a simple easy to crack V8's Boot loader need to implement USB device connectivity; Product: J-Link emulation is SEGGER company ARM core chip to support the launch of the JTAG emulator. With the IAR EWARM, ADS, KEIL, WINARM, Real View and other integrated development environment supports all ARM7/ARM9 core chip simulation Through RDI interface and the integrated development environment for seamless connectivity, easy, convenient connections Easy to learn, is learning and developing ARM best and most practical development tools. J-Link ARM Features: 1. IAR EWARM integrated development environment seamlessly connected JTAG Emulator 2. Support all ARM7/ARM9 core chips, as well as cortex M3, including Thumb mode 3. Support for ADS, IAR, KEIL, WINARM, REALVIEW almost all of the development environment 4. Download speeds of up to ARM7: 600kB / s, ARM9: 550kB / s, through the DCC up to 800 kB / s 5. The maximum JTAG speed 12 MHz 6. Target board voltage range 1.2V-3.3V, 5V compatible 7. Auto speed recognition 8. Monitoring all JTAG signals and target board voltage 9.Fully plug and play 10. Use the USB power supply (but not the target board power supply) 11. With a USB cable and 20-core flat cable 12. Support multi-device JTAG serial connection 13. Standard 20-core JTAG emulation connector 14. Optional 14-core JTAG emulation connector 15. Optional adapter for 5V targets board J-Link support for ARM cores: * ARM7TDMI (Rev 1) * ARM7TDMI (Rev 3) * ARM7TDMI-S (Rev 4) * ARM720T * ARM920T * ARM926EJ-S * ARM946E-S * ARM966E-S * ARM11 * Cortex-M3 Specifications USB power supply, the whole current <50mA USB Interface USB 2.0 full speed 12Mbps Target board interfaces JTAG (20P) J-Link and target board serial data transfer speed between the 12MHz maximum Supported target board voltage 1.2 - 3.3V, 5V compatible Target board power supply voltage 4.5 - 5V (provided by the USB 5V) Target board power supply current max 300mA, with overcurrent protection Operating temperature +5 ° C ...+60 ° C Storage temperature -20 ° C ... +65 Humidity <90% Size (without cables): 103mm x 53mm x 27mm Weight (without cable): 60g EMC EN 55022, EN 55024 Supported Operating Systems Microsoft Windows 2000 Microsoft Windows XP Microsoft Windows XP x64 Microsoft Windows 2003 Microsoft Windows 2003 x64 Microsoft Windows Vista Microsoft Windows Vista x64 Package Contains: 1x J link V8 ARM Emulator 1x USB Cable 1x Connector Cable 1x CD -Paypal only. -Please make payment asap,then we can arrange shipment for you asap. -We only ship to Paypal confirmed address. for international Buyers, We only Shipping to Paypal Verify user.Before you Biding,verify your paypal account please. On 08-Nov-14 at 03:30:51 EST, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Other
Country/Region of Manufacture	China
