1pc 4s 18650 Lithium Battery Protection Board 14.8v 16.8v Working Current 6a

US $6.39

shenzhen, China
Jan 29th

Open on mobile:
QR code

NOTE: Replace the battery protection board, and if the amount is no voltage output, use the lithium battery charger 12.6V recharged activate the output voltage of the protective plate there. Lithium Battery 10.8V; 11.1V; 12V; 12.6V voltage are the same, the same battery, battery parameters are the same, the charge / discharge performance is the same Scope: 10.8V (3.6V * 3 strings) lithium batteries 11.1V (3.7V * 3 strings) lithium batteries 12V (4V * 3 strings) lithium batteries 12.6V (4.2V * 3 strings) lithium batteries Available cylindrical lithium combination; polymer lithium battery combination; square lithium combination Parameters: Single maximum protection voltage: 4.25V ± 0.025V Single minimum protection voltage: 2.80V ± 0.1V Maximum operating current: 8A Maximum instantaneous current: 14A Protection: over charge protection; Over discharge protection; overcurrent protection, short circuit protection Size: 48mm * 20mm * 3.1mm · B-connected to the negative terminal of a battery; · 3.6V-battery cathode connected to the first and second contacts in series with the battery negative; · 7.2V-connected second battery positive and negative battery third series of contacts; · 10.8V-connected third battery positive; · P + connection charge / discharge upright pole (charging terminal / discharge side shared); · P-connection charge / discharge end of the negative (charging terminal / discharge side shared).
