1pc General Universal Automatic Voltage Regulator Avr Ea16 Generator/genset Part

US $144.87

HongKong, Hong Kong
Jan 29th

Open on mobile:
QR code

1pc General Universal Automatic Voltage Regulator AVR EA16 Generator/Genset Part Description 1pc General Universal Automatic Voltage Regulator AVR EA16 Generator/Genset Part Features Voltage Regulation < ±0.5% Suitable for brushless type generator Sensing Input 170~510 VAC Can be used in Parallel Operation 16 ADC Current Output EA16 Suitable Frequency 50/60 Hz , EA16-400Hz Suitable Frequency 400 Hz Soft Start Voltage Ramping Load CT Current Compensation, Analogue Voltage Input Specifications Model NO. EA16 EA16-400Hz Sensing Input Voltage 170~510 VAC single phase 2 wire Voltage 170~510 VAC single phase 2 wire Frequency 50/60 Hz Frequency 400 Hz Power Input Voltage 60~300 VAC single phase 2 wire Voltage 60~300 VAC single phase 2 wire Max. 90 VDC @ 240 VAC input Output Voltage Max. 90 VDC @ 240 VAC input Current Continuous 16A, Max. Intermittent 20A for 10 sec. Resistance Min. 6 Ohm @ 35 VDC Voltage Max. 90 VDC @ 240 VAC input Current Continuous 16A, Max. Intermittent 20A for 10 sec. Resistance Min. 6 Ohm @ 35 VDC Voltage Regulation < ±0.5% (with 4% engine governing) < ±0.5% (with 4% engine governing) Voltage Build-up Residual volts at AVR terminal > 5 VAC Residual volts at AVR terminal > 5 VAC External Volts Adjustment ±5% with 2 K Ohm 1 watt trimmer ±5% with 2 K Ohm 1 watt trimmer Unit Power Dissipation Max. 10 watt Max. 10 watt Thermal Drift 0.03% per °C change in AVR ambient 0.03% per °C change in AVR ambient Under Frequency Protection 55 Hz @ 60 Hz / 45 Hz @ 55 Hz (Adjustable) 360 Hz (Adjustable) CT Current Compensation Input 1A or 5A (Selectable) 1A or 5A (Selectable) Analogue Input ±5 VDC ±10% AC @ ±3 VDC ±5 VDC ±10% AC @ ±3 VDC Environment Operating Temperature : -40~70 °C Storage Temperature : -40~85 °C Relative Humidity : Maximum 95% Vibration : 3.3G @ 100~2 KHz Operating Temperature : -40~70 °C Storage Temperature : -40~85 °C Relative Humidity : Maximum 95% Vibration : 3.3G @ 100~2 KHz AVR Controls Functions VOLT : Voltage Adjustment STAB : Stability Adjustment U/F*: To Set the U/F Knee Point DROOP : To Adjust Droop TRIM : Analogue Input Adjustment (*U/F: Under Frequency Protection) VOLT : Voltage Adjustment STAB : Stability Adjustment U/F*: To Set the U/F Knee Point DROOP : To Adjust Droop TRIM : Analogue Input Adjustment (*U/F: Under Frequency Protection) Dimensions 156.0 (L) x 106.0 (W) x 43.0 (H) mm 156.0 (L) x 106.0 (W) x 43.0 (H) mm Weight 450 g ±2% 450 g ±2% Package includes: 1 x piece Payment • We accept only Paypal payment. • We expect payment within 7 days of winning, you can wait until you have all done shopping, and then pay all together at the end (within a 7days period), it will allow us to ship your items together. Delivery details Estimated Delivery time (NOT Guaranteed, as shipping depends on the post office, custom, buyer address, airport etc): Express shipping: DHL/UPS/Fedex 3-10 working days Post mail shipping: United States: 7-20 working days United Kingdom / Australia 10-30 working days. Canada 10-30 working days. France / Spain / Germany may take10-30 working days. Eastern Europe may take up to 16-40 working days. Italy / Russia/ Ukraine/ Brazil / South America may take up to 30-50 working days. • Item will be shipped within 2 working days after full payment is received. Buyer is under obligation if (in case) the item is liable to your country's customs duties. We are not responsible for your country's any taxe or customs fee. • We only ship to the approved address given on eBay. Please make sure the address is correct. Any non-received items caused by invalid address registered on eBay are not in our full refund or replacement policy. • A notification email of dispatch will be sent to buyer after item is posted. Please email us if you don't receive our email after 5 days of full payment sent. Return Policy • In the unlikely event that a return is request, all returns must include all original items undamaged, same condition as seller sent, in re-saleable condition, all original packaging including manuals, warranty forms, etc. • Shipping and handling fees are not refundable. Buyer is responsible for shipping costs incurred shipping products back. Feedback & Contact Us • If you received the item and satisfy, please leave positive feedback to support us, we will do the same as well. • Before leaving any negative/neutral feedbacks, you can contact us if you have any problems, we are always happy to resolve it for you. • Please contact us using eBay's "Contact Seller" function, we will respond within 24 hours usually (except weekend and holiday). About replaies 1.If there is any question, please feel free to contact us. we will give you the answer as soon as we can. Our pleasure to serve you. 2. We are open from Monday to Friday. Engineered for professional eBay sellers!
