1pc Nrf24l01+ Antenna Wireless Transceiver Module For Microcontroller Arduino

US $2.19

Singapore, Singapore
Jan 29th

Open on mobile:
QR code

Shipping Payment Return Policy&Feedback Contact Us Product Show Desription NRF24L01 + 2.4GHz RF Wireless Transceiver Module 1. The real GFSK monolithic transceiver chip 2. Built-in hardware and link layer 3. Automatic response and automatic retransmission function 4. Address and CRC check function 5. Wireless rate: 1 or 2 MBPS 6. SPI interface rate: 0 ~ 8MBPS 7. 125 optional channels work 8. Channel switching time is very short, can be used for frequency hopping 9. Fully compatible with nRF24XX series 10.I/O can accept 5v level of input 11.±60ppm 16MHz crystal 12.Low working voltage: 1.9 ~ 3.6 V 13.The global open ISM frequency band, the maximum 0dbm transmitted power, free license to use. 14.Transmission distance up to 100 meters in outdoor open occasions! nRF24L01 is a single chip radio transceiver for the world wide 2.4 - 2.5 GHz ISM band. The transceiver consists of a fully integrated frequency synthesizer, a power amplifier, a crystal oscillator, a demodulator, modulator and Enhanced ShockBurst? protocol engine. Output power, frequency channels, and protocol setup are easily. programmable through a SPI interface. Current consumption is very low, only 9.0mA at an output power of -6dBm and 12.3mA in RX mode. Built-in Power Down and Standby modes makes power saving easily realizable. Maximum operating speeds up to 2Mbps, GFSK modulation efficiency, Anti-interference ability, Particularly suitable for industrial control applications. 125 Communications channels, Multi-point communication and frequency hopping to meet the communication needs. Built-in hardware CRC error detection, Multipoint communication address control. Low-power 1.9 ~ 3.6V, only 1uA on Power down mode. Built-in 2.4Ghz antenna. Available software to set the address, only received local Address when output data(Provide interrupt instruction), can be directly connected to a variety of microcontrollers, Software programming is very convenient. Support 6 Data channels of data reception. Standard DIP Pitch Interface for embedded applications. Notice: Transceivers integrated module , transmit or receive can not be simultaneously by one module. NRF24L01 + 2.4GHz RF Wireless Transceiver Module x 1 Shipping Item will be shipped within 24 -48 hours after full payment is received. The Item will be shipped by air mail,Normally the shippment to worldwide is used to take 20 to 25 business days, exclude Sat & Sun. Payment We only accept payment through Paypal. Payment must be received in 7 business days of auction closing. Please leave note for your special request in ebay note when you pay the order. Any special request cannot be accepted after 24 hours of payment, because most of orders will be processed instantly and same day dispatched. Return Policy&Feedback If the item is defect when you receive it or you are not satisfied with it, please return it within 14 days for a replacement or money back. But the items must be back in factory condition. Please contact us and double check the return address before you return it. If is item is defective in 3 months, you can return it to us. We will send you a new replacement after receiving the defective item Contact Us We care about our valued buyers, if you have any questions, our Customer Service staffs will be very glad to help you. We try our best to reply your email as soon as possible, please kindly allow 24 hours(working day) for us to response. Thank you. We greatly appreciate your POSITIVE feedback. Please do NOT leave negative or neutral feedback without any contact
