1pc Plj-6led-a Frequency Display Component / Frequency Meter Blue

US $9.99

???, ???, China
Jun 9th

Open on mobile:
QR code

PLJ-6LED-A frequency display component / frequency meter blue Description PLJ - 6 leds - A is designed for the HAM friends of cost-effective six LED display module, frequency is mainly used for transceiver equipment such as frequency values show, also can be used in the conventional frequency measurement. This module is compact, reliable performance, good visual effect, low cost, etc. Main features: 1 PIC16F628A Microchip company as the core of 65 MHZ frequency meter. Type 2 frequency reference with temperature compensation voltage controlled crystal oscillator (+ / - 2.5 PPM VC - TCXO). 3 adopt unique gate control mode and precision of algorithm. 4 gate time of 0.1 seconds (display refresh), real-time display frequency values. 5 10 hz / 100 hz frequency measurement precision (right one) is optional. 6 double medium frequency design, intermediate frequency value and add/subtract mode can be preset alone, each other. 7 shows driver using special chip LED display, digital tube high brightness, less foreign interference. 8 using six 0.56 -inch digital tube display, automatic blanking invalid zero, changing the brightness is adjustable. 9 simple circuit, reasonable structure, double button control, simple operation. Each set automatically saved 10, boot direct call. Technical parameters 1. The gate time 0.1 seconds 2. The measurement channels Input impedance: high resistance Measuring range: 0.1 MHz to 65 MHz The accuracy of measurement: 10 Hz Sensitivity: better than 60 MVPP 3. The intermediate frequency setting Independent double medium frequency design, intermediate frequency adjust the minimum interval is 100 Hz, the medium frequency range of 0 ~ 99.9999 MHz, can be set up and intermediate frequency Or minus intermediate frequency mode. 4. The frequency benchmark Using 5032 size 13.000 MHz removing voltage-controlled crystal oscillator (VC - TCXO), frequency stability is plus or minus 2.5 PPM. 5. Working voltage DC input: 8 v to 15 v DC (power supply polarity reverse connect protection) or DC 5 v (hardware setup required). Working current is 6. Maximum 90 mA 7. According to figures Six common anode LED display, the highest according to six figures. 8. Display brightness 8 LED brightness is adjustable, the factory is set to the highest intensity. 9. Physical size Length x width x height: 91 mm x 28 mm x 20 mm 10. The onboard interface The RF signal input (IN) : HX2.54-2 p socket ICSP (programming interface) : 2.54-6 p pin DC power supply interface (IN) : HX2.54-2 p socket We only accept Paypal in Ebay. If you want to pay via other method please contact us. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to biding Item will be shipped within 24 hours on payment received from Hong Kong using Airmail. Delivery time depends on destination and other factors, it may takes up to 30 business days. Optionally, Express Shipments with tracking service via EMS/DHL/UPS with a quoted delivery time of 5 to 7 business days is also available Here is the estimated time for your reference only: The delivery time may vary due to public holidays, countries, and customs etc. Thanks for your understanding You feedback is very important to us, please let us know before leaving any negative feedback or open any disputes on Paypal, please give me an opportunity to resolve any problems and we will try our best to satisfy your requirement. If the item is defective, please let me know as soon as possible after receive the items. The item will be returned its original condition, in order to get it refunded and replaced (please inquire us the returning address before you ship it back.) . Buyer is responsible for shipping costs when shipping products.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Agilent
MPN	Does Not Apply
UPC	Does Not Apply
