Transistor Tester Detect IC Tester Meter Maintenance Tester Demo video link: http://v.youku.com/v_show/id_XMzQ5NzI1ODgw.html Description:\ The multi-function integrated circuit tester is a professional instrument designed for the first-line microelectronic engineering staff , maintenance staff . Different test mode can be selected 5v mode , 3.3v mode , AUTO mode can test 74HC series 74LS series , CD4000 series , HEF400 Series , 4500 Series , operational amplifiers, interface class chip , optocoupler transistor automatic identification regulator regulator value recognition , and so on . Built-in 13 kinds of various types of chip data model , the transistor data model more than 420 kinds , covering a majority of 24 feet or less common universal device , can significantly reduce the workload and improve work efficiency Operating instructions: The panel has 5 buttons are on the left, right, bottom, and Enter keys. The next key is used to adjust the directory and change the model number, the or so key to move around the cursor options to change.The Enter key for the switch machine and execute the test command.Gently open the battery cover, add a 9V laminated battery, and then close the battery cover.Press Enter for more than 2 seconds can boot, boot automatically display the current battery voltage, when the voltage is lower than 7.5, please replace the battery, the low voltage will affect the reliability of the test result and protection automatic shutdown. Boot: Enter key press 2 seconds then boot. Shutdown: 1 in the OFF directory, press Enter button to immediately shutdown. 2 in any directory, press Enter button for more than 10 seconds then off. 3 in no operation after 60 seconds, automatic shutdown Methods of devices placed: 1, the top of the chip alignment 2, put the most left transistor three slot 3, a 13 foot alignment IC Optocoupler 4, voltage regulator tubes placed IC block 13 and 14 feet. Note: the transistor display pin order from left to right and the corresponding IC block, 10 feet, 11 feet, 12 feet catalogue function Search Auto mode Device search , the unknown model chip inserted in ic seat can automatically identify the part number ( Automatic identification without input) ( other directories are auto- mode ) 5.0v mode 3.3v mode 74HC 74HC series of logic device test (of the same, and 74LS series base drive level (different) need to manually enter the model) 74LS 74LS series of logic device test (of the same, and 74HC series base drive level (different) need to manually enter the model) CD40 CD4000 series of logic device test (different, and HEF40 series base drive level (the same) need to manually enter the model) HEF40 HEF4000 series of logic device test (different, and CD40 series base drive level (the same) need to manually enter the model) 45/145 45 series 145 series logic device test (the need to manually enter the model) OTHER Interface drive device testing, such as: MAX232, MAX485, 75175, 75176, 75c11.. (the need to manually select the model) AMP Operational amplifier, comparator class testing, such as: LM324, LM358, LM339, LM393, LM2902...(the need to manually enter the model). TR Transistor identification , and automatically determine the transistor types and pin order . Identifiable NPN , PNP, transistors , N- MOS , P -MOS way thyristor , triac , common anode common cathode rectifier automatic identification without input ) ZD Zener regulator value test , test regulator regulator 0v-50v range accuracy 0.01v automatic identification without the need to enter LIGHT Optocoupler secondary the saturation voltage test , can test the the ordinary 4 feet optocoupler secondary saturation voltage automatic identification without input ) OFF Shutdown prompt explanation OK Tests are normal Batter Battery voltage Not found Can’t find Fault The chip damaged or type mismatch Open Open circuit Not supported nonsupport NPN Triode PNP Triode N-MOS FET P-MOS FET 1-SCR Way SCR 2-SCR Triac 2D Common cathode and common anode rectifier A?k?b?c?e?g? Specific pin Out of range Zener voltage beyond the scope ERR1?2 Self-test failure Shipping & Handling Policy Generally, delivery time is 10-20 business days to USA, United Kingdom, Australia and 15-30 days to most other countries. All orders will be processed within 48 hours from the date of payment .The delivery confirmation will be sent ebay message when your order is processed We will make shipment according to the address you put on eBay, if you want us to ship items to a different address please contact us before making the payment. International Buyers Note: 1) Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. 2) Please check with your country's customs office to determine what these additional costs will be prior to bidding/buying. Payment Policy We accept Paypal only. Returns Policy We always take customer service seriously and want you to be 100% happy with your shopping experience here. If you are unsatisfied with our item or service, then please follow the good eBay practice to contact us before leaving any feedback and return it within 14 days for a replacement or money back. Please contact me before you return it. Buyer is responsible for the shipping cost of return postage. Shipping and insurance costs will not be refunded. We are committed to resolve all issues in a friendly and satisfactory manner. Contact us If you have any problems, we are very glad to help you. We are handling large volume emails every day. Please allow us to reply your email within 24hrs Feedback Dear buyers, we appreciate your business, if you are satisfied with our service, please leave us a positive feedback . When you rate the shipping time part please take international transit into consideration. Your recognition will make us more confident to develop business and serve you better. Our goal is to make sure you are a happy buyer and pleasant shopping with us. Please email us before leaving any 1 or 2 ratings, negative feedback or open any dispute. We understand the concerns and frustrations you might have, and will do our endeavor to resolve the issues. Please give us the opportunity to resolve any problem. thank you ! On Sep-22-14 at 02:25:39 PDT, seller added the following information:
