1pcs 12864 128X64 Yellow/Green Dots Graphic Matrix LCD Display Module LCM 5V new, US $9.18 – Picture 0
1pcs 12864 128X64 Yellow/Green Dots Graphic Matrix LCD Display Module LCM 5V new, US $9.18 – Picture 1
1pcs 12864 128X64 Yellow/Green Dots Graphic Matrix LCD Display Module LCM 5V new, US $9.18 – Picture 2
1pcs 12864 128X64 Yellow/Green Dots Graphic Matrix LCD Display Module LCM 5V new, US $9.18 – Picture 0
1pcs 12864 128X64 Yellow/Green Dots Graphic Matrix LCD Display Module LCM 5V new, US $9.18 – Picture 1
1pcs 12864 128X64 Yellow/Green Dots Graphic Matrix LCD Display Module LCM 5V new, US $9.18 – Picture 2

1pcs 12864 128x64 Yellow/green Dots Graphic Matrix Lcd Display Module Lcm 5v New

US $9.18

  • shenzhen, China
  • Jun 9th
Open on mobile:
QR code
Product Name: 1pcs 12864 128X64 Yellow/Green Dots Graphic Matrix LCD Display Module LCM 5V new More Items In Our Store,Click Here!   SKU: 2032 Parsts No. : Package: Brand:   Quantity: 1   The controller of this LCD is a ST7920: Items  size unit Module volume 93 X 70 X13 mm View area 72 X40 mm Point distance  0.52 X 0.52 mm Point size 0.48 X0.48 mm Parallel mode interface definition: Pin number definition level Function specification 1 VSS 0V Power supply negative 2 VDD +5V Power supply positive 3 V0 - Contrast control 4 RS H/L RS=H:shows data  RS=L:controls instruction 5 R/W H/L R/W+H,E=H,data was read DB7-DB0 R/w=L,E=H=L:the data of DB7-DB0 was written to IR or DR 6 E H/L Enable pin 7-14 DB0-DB7 H/L Data line 15 PSB H/L PSB=H,parallel mode,PSB=L,serial mode 16 NC - Empty pin 17 /RESET H/L Reset terminal,low level valid 18 Voult - Module drives voltage output terminal 19 A +5V Backlight power supply positive 20 K 0V Backlight power supply negative  Serial module interface definition: Pin number definition level Function specification 1 VSS 0V Power supply negative 2 VDD +5V Power supply positive 3 V0 - Contrast control 4 CS H/L Chip selection terminal,high level valid 5 SID H/L Serial data input terminal 6 CLK H/L Serial synchronous clock 15 PSB H/L PSB=H,parallel mode,PSB=L,serial mode 17 /RESET H/L Reset terminal,low level valid 19 A +5V Backlight power supply positive 20 K 0V Backlight power supply negative      Any problem, please contact us freely       1) We accept PayPal payment ONLY.     On Jan-29-15 at 19:36:43 PST, seller added the following information:
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand Unbranded
MPN Does Not Apply
Model LCD12864
Country/Region of Manufacture China
UPC Does not apply
