1pcs 5V 1-Channel Relay Module with Optocoupler High Level Triger for Arduino, US $160 – Picture 0
1pcs 5V 1-Channel Relay Module with Optocoupler High Level Triger for Arduino, US $160 – Picture 0

1pcs 5v 1-channel Relay Module With Optocoupler High Level Triger For Arduino

US $160

  • Shenzhen, China
  • Jun 9th
Open on mobile:
QR code
Click to Enlarge Click to Enlarge Product Name: 1pcs 5V 1-Channel Relay Module with Optocoupler High Level Triger for Arduino More Items In Our Store,Click Here!   SKU: 3358 Parsts No. : Package: Brand:   Quantity: 1   1 Channel Relay 2 Channel Relay 3 Channel Relay 4 Channel Relay 6 Channel Relay 8 Channel Relay   1. this module conform international safety standard, the isolation groove between control areas and load area; 2. with optical coupling isolation, triggering more reliable, more stable; 3. the double FR-4 circuit board design; 4. have power and relay operation instructions.The LED will be lit when relay on; 5. signal input with a high level signal, the common pin; 6. relay can directly control all kinds of equipment and load; 7. one normally open pin and a normally closed pin; 8. blue KF301 terminal, more convenient; 9. module size: 53x18x18.5mm; Module interface: Input part: VCC:connect to power positive (according to the relay voltage range) GND: connect to power negative IN: relay module trigger pin (high level trigger) Output part: Normally Opened (NO) : normally open pin of relay. NO pin is not connect to COM pin when relay off.NO pin is connect to COM pin when relay on; Common pin (COM) : Common pin of the relay; Normally closed (NC) : normally close pin of relay.NC pin is connect to COM pin when relay off.NC pin is not connect to COM pin when relay on; Electrical parameters: Voltage version:5V The static current:4mA Working current:65mA Trigger voltage:2-5V Trigger current:2mA   Any problem, please contact us freely       1) We accept PayPal payment ONLY.     On Mar-26-14 at 00:59:56 PDT, seller added the following information: <> <> <> On Feb-10-15 at 19:41:53 PST, seller added the following information:
