1pcs 5v Delay Relay Module With Led Indicator 0-10 Seconds Delay New

US $190

Shenzhen, China
Jun 9th

Open on mobile:
QR code

Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Product Name: NEW ICSE025A 5V Delay Relay Module With the relay closing indicator More Items In Our Store,Click Here! SKU: 5326 Parsts No. : Package: Brand: Quantity: 1 ICSE025A 5V Delay Relay Module Feature 1.Connect with the power,then the relay delays closing. 2.The delay time is adjustable,(0-10 seconds). 3.Increase potentiometer can increase the delay time. 4.Increase the capacitance C1 can increase the delay time. 5.With the input power indicator. 6.With the relay closing indicator. 7.It can control the equipment under 220V/10A(maximum 2000W). 8.With continuous current protection. 1.Application MCU learning, electronic competition, product development,graduation design 2.Specifications Main chip:NE555 Working voltage:5V DC Delay time:0~10 S Size:6.8CM*2.1CM 3.Mechanical drawing 5.Schemetic 6.Port description ?CK?: The constant opening port of relay.Connect with ?COM?when relay is not closing ?COM?:Relay public port. ?CB??The constant closing port of relay.Connect with ?COM? when relay in closing. Any problem, please contact us freely 1) We accept PayPal payment ONLY. On Jan-30-15 at 03:00:26 PST, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Delay Relay Module
UPC	Does not apply
Model	Delay Relay Module
Type	Does not apply
MPN	Delay Relay Module
Color	Does not apply
Country/Region of Manufacture	China
Material	Does not apply
