1pcs. Ads1216y 8-channel, 24-bit Analog-to-digital Converter

US $12.00

Krasnodar, Krasnodarskiy kray, Russian Federation
Jan 29th

Open on mobile:
QR code

Description The ADS1216 is a precision, wide dynamic range, delta-sigma, Analog-to-Digital (A/D) converter with 24-bit resolution operating from 2.7V to 5.25V supplies. The delta-sigma A/D converter provides up to 24 bits of no-missing-code performance and an effective resolution of 22 bits. The eight input channels are multiplexed. Internal buffering can be selected to provide a very high input impedance for direct connection to transducers or low-level voltage signals. Burnout current sources are provided that allow for the detection of an open or shorted sensor. An 8-bit Digital-to-Analog Converter (DAC) provides an offset correction with a range of 50% of the FSR (Full-Scale Range). The PGA (Programmable Gain Amplifier) provides selectable gains of 1 to 128 with an effective resolution of 19 bits at a gain of 128. The A/D conversion is accomplished with a second-order delta-sigma modulator and programmable sinc filter. The reference input is differential and can be used for ratiometric cancellation. The onboard current DACs operate independently with the maximum current set by an external resistor. The serial interface is SPI-compatible. Eight bits of digital I/O are also provided that can be used for input or output. The ADS1216 is designed for high-resolution measurement applications in smart transmitters, industrial process control, weight scales, chromatography, and portable instrumentation. Features 24 BITS, NO MISSING CODES 0.0015% INL 22 BITS EFFECTIVE RESOLUTION (PGA = 1), 19 BITS (PGA = 128) PGA FROM 1 TO 128 SINGLE-CYCLE SETTLING MODE PROGRAMMABLE DATA OUTPUT RATES: up to 1kHz ON-CHIP 1.25V/2.5V REFERENCE EXTERNAL DIFFERENTIAL REFERENCE: 0.1V to 2.5V ON-CHIP CALIBRATION SPI™-COMPATIBLE 2.7V TO 5.25V < 1mW POWER CONSUMPTION APPLICATIONSINDUSTRIAL PROCESS CONTROL LIQUID/GAS CHROMATOGRAPHY BLOOD ANALYSIS SMART TRANSMITTERS PORTABLE INSTRUMENTATION WEIGHT SCALES PRESSURE TRANSDUCERS Shipping with tracking.

Condition:

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...

Brand

Burr Brown
