(1PCS) APT100GN120B2G IGBT 1200V 245A 960W TMAX 100GN120 APT100GN120, US $170 – Picture 0
(1PCS) APT100GN120B2G IGBT 1200V 245A 960W TMAX 100GN120 APT100GN120, US $170 – Picture 0

(1pcs) Apt100gn120b2g Igbt 1200v 245a 960w Tmax 100gn120 Apt100gn120

US $170

  • Shenzhen, China
  • Nov 4th
Open on mobile:
QR code
APT100GN120B2G Desciption Part NO. APT100GN120B2G Package TO-247-3 Variant Description IGBT 1200V 245A 960W TMAX IGBT Type Trench and Field Stop Voltage - Collector Emitter Breakdown (Max) 1200V Vce(on) (Max) @ Vge, Ic 2.1V @ 15V, 100A Current - Collector (Ic) (Max) 245A Current - Collector Pulsed (Icm) 300A Power - Max 960W Switching Energy 11mJ (on), 9.5mJ (off) Input Type Standard Gate Charge 540nC Td (on/off) @ 25°C 50ns/615ns Test Condition 800V, 100A, 1 Ohm, 15V Reverse Recovery Time (trr) - Mounting Type Through Hole Supplier Device Package * Store Website http://stores.ebay.com/SICSTOCK-Store Datasheet http://www2.microsemi.com/document-portal/doc_download/6562-apt100gn120b2-g-a-pdf On Nov-04-16 at 08:58:11 PDT, seller added the following information:
