1pcs Diy Kit Remote Control Multi-function Rotating Electronic Clock

US $1700

Shenzhen, China
Jun 22nd

Open on mobile:
QR code

Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Product Name: DIY Kit Remote Control Multi-Function Rotating Electronic Clock More Items In Our Store,Click Here! SKU: 4999 Parsts No. : Package: Brand: Quantity: 1 Remote Control Multi-Function Rotating Electronic Clock DIY Kit 1. Function. 1>. It is DIY kit. User need to weld it. 2>. Clock display. Display hour and minutes minute under normal circumstances on 4-Bit digital tube. 3>. Display seconds on LEDs. 4>. Hour,minute and second can be adjusted independently. 5>. Timekeeping function. 6>. 2-Channel independent alarm. 2. NOTE. 1>. There are 13 short circuit pad marked J1 to J13. User can weld it by pin from other components such as metal film resistors or LEDs. 2>. DC2 on PCB is standby power. 3>. Input power is 4.5V-5.5V. If users don?t use standby power ,you don?t need weld VD1-2(1N5819) on PCB but need to weld pad which has marked ?A?. 3. Component listing. Component Number Parameter Quantity Electrolytic capacitor C1 10uF 1 Ceramic capacitor C2,C3 30pF 2 0805 Capacitor C4,C6-C12 104 8 Electrolytic capacitor C5 220uF 1 Electrolytic capacitor C13 100uF 1 1*2P Male pin DC5V 2.54mm 1 4Bit digital tube DS1 1 74HC595 IC1-IC5 SOP-16 5 20P IC Socket IC6 1 STC11F04 DIP-20 1 3mm LED LED5,LED10,LED15,LED20, LED25,LED30,LED35,LED40, LED45,LED50,LED55,LED60 Red 12 3mm LED White 48 Buzzer LS1 1 S8550 Q1-Q7 SOT-23 7 0805 Resistor R1-R68 R80 470ohm 69 0805 Resistor R69-R73,R76,R76,R77,R79 10K 8 Metal film Resistor R74,R75 10K 2 0805 Resistor R78 5.1K 1 6*6*5 Button S1,S2,S3 3 HC-49S Crystal Y1 12MHz 1 1N5819 VD1-2 1 PCB 1 DS18B20 DS2 TO-92 1 IR receiver H1 HX1838 1 Infrared remote control 1 4. Button Debugging Instructions: Button S1: Reset button. Button S2: Mode selection button Button S3: Function control buttons Mode(Display on first 2 Bits) Function Debug(Display on 2Bits from right) 01 Display and Correction seconds Correction seconds can be used as a stopwatch 02 Display and Correction minutes Correction minutes 03 Display and Correction hours Correction hours 04 Hourly timekeeping 0:Timekeeping at 00:00-23:00 1:Timekeeping at 7:00-22:00 2:Close Timekeeping 05 Adjust the time speed 0-99 Position. Default 50 The higher the number, the faster time 06 1-Channel Alarm Clock minutes adjustment Display and adjustment 07 1-Channel Alarm Clock hours adjustment Display and adjustment 08 2-Channel Alarm Clock minutes adjustment Display and adjustment 09 2-Channel Alarm Clock hours adjustment Display and adjustment Button S3: Function control buttons 5. Infrared remote control instructions: 1>. Button ?0? :Display status 0. 60pcs LEDs display overlay. 2>. Button ?1?: Display status 1. 60pcs LEDs flash display. 3>. Button ?2?: Display status 2. 60pcs LEDs water lights display. 4>. Button ?U/SD?: Open/Close display 12 Hourly time LED(Red LED). 5>. Button ?Power?:Close all display. 6>. Button ?Mute?: Close all timekeeping function. 7>. Button ?EQ?:Display current temperature. 8>. Button ?Mode?:Enter debug status. 6. Infrared remote control debug instructions: 1>. Button ?0-9?: Enter status 0-9(Reference ?Button Debugging Instructions?). 2>. Button ?Pre? and ?Next?:Status plus 1 or minus 1. (Display on first 2 Bits) 3>. Button ?VOL-? and ?VOL+?: Debug(Display on 2Bits from right) 4>. Quit status and normal display. Any problem, please contact us freely 1) We accept PayPal payment ONLY. On Mar-05-15 at 22:15:18 PST, seller added the following information:
