1pcs Drv8871 H-bridge Dc Motor Driver Breakout Board 3.6a Pwm Control Module

US $3.88

, , China
Jul 16th

Open on mobile:
QR code

1PCS DRV8871 H-Bridge DC Motor Driver Breakout Board 3.6A PWM Control Module 1 Features 1• H-Bridge Motor Driver – Drives One DC Motor, One Winding of a Stepper Motor, or Other Loads • Wide 6.5-V to 45-V Operating Voltage • 565-mΩ Typical RDS(on) (HS + LS) • 3.6-A Peak Current Drive • PWM Control Interface • Current Regulation Without a Sense Resistor • Low-Power Sleep Mode • Small Package and Footprint – 8-Pin HSOP With PowerPAD™ – 4.9 × 6 mm • Integrated Protection Features – VM Undervoltage Lockout (UVLO) – Overcurrent Protection (OCP) – Thermal Shutdown (TSD) – Automatic Fault Recovery 2 Applications • Printers • Appliances • Industrial Equipment • Other Mechatronic Applications 3 Description The DRV8871 device is a brushed-DC motor driver for printers, appliances, industrial equipment, and other small machines. Two logic inputs control the Hbridge driver, which consists of four N-channel MOSFETs that can control motors bidirectionally with up to 3.6-A peak current. The inputs can be pulsewidth modulated (PWM) to control motor speed, using a choice of current-decay modes. Setting both inputs low enters a low-power sleep mode. The DRV8871 device has advanced currentregulation circuitry that does not use an analog voltage reference or external sense resistor. This novel solution uses a standard low-cost, low-power resistor to set the current threshold. The ability to limit current to a known level can significantly reduce the system power requirements and bulk capacitance needed to maintain stable voltage, especially for motor startup and stall conditions. The device is fully protected from faults and short circuits, including undervoltage (UVLO), overcurrent (OCP), and overtemperature (TSD). When the fault condition is removed, the device automatically resumes normal operation. Payment Returns Shipping Payment We only accept payment through Paypal. Items will go to post within 1-2 business days after payment confirmed. Returns If you can't receive the product within 2 months (60 days), please contact with us,we promise to payback 100% of your money. We ensure our products work normally before post.If the products is broken before arrival to you,all you should do is taking a photo to show us our broken product.We promise to payback 100% of your money. Shipping 1. We ship to Worldwide. 2. We only ship to confirmed PAYPAL address; your PAYPAL address must match your Shipping address. 3. Any non-received items caused by invalid address registered on PayPal are not in our full refund or replacement policy. Shipping fee has including the local handing and packaging fee. 4. All the items will be shipping within 1-2 working days after receiving the payment, except some holidays. 5. We will not be responsible for any custom delay or tax, because transit time is highly depended and provided by postal Service. 6. If you have any problem, please contact us via message, we will reply message within 1-2 working days, please wait for patient.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
UPC	Does not apply
MPN	Does not apply
EAN	Does not apply
