1pcs Hc-11 To Ttl Cc1101 Module 433mhz Replace Wireless Bluetooth New

US $5.46

shenzhen, China
Jun 9th

Open on mobile:
QR code

Product Name: HC-11 433Mhz Wireless to TTL CC1101 Module Replace Bluetooth More Items In Our Store,Click Here! SKU: 3343 Parsts No. : Package: Brand: Quantity: 1 PS:HC-11 can not connect to HC-12.Their work is independently each other. Features: 1: Silent current 3. 4ma, ultra-low power consumption. 2: long distance, range 1 to 40m.(less than 1 m, module can't work normally). 3: support 3.3V~5V. 4: support serial pass-through mode, replacing serial line (half duplex). 5: support IO level,also means transmitting digital level model. 6: support IO level latch mode. 7: can set the frequency point, set the address, automatic filtering. 8: module size: 27.8mm*14.4 mm*4 mm. 9: suitable for network design. 10: module supporting software upgrades. Pin define: The antenna connection: Introduction of the module: 1: FU1 mode: The default delivery mode. 2: FU2 mode: The IIDLE current is 80uA,but longer delay, transmission delay is close to 400ms.When use this mode,the serial port baud rate only can be 4800, 2400, 1200.Because of long time delay, when the continuous send serial data to the module, can only send 245 bytes of data by once.Low current consumption, suitable for the application of low power consumption. 3: FU3 mode: Transmission delay has been reduced to less than 8ms, the corresponding power consumption also increased slightly. 4: FU4 mode: Transmission distance is longer, the lower baud rate, the longer the transmission distance, the corresponding transmission delay is also a slight increase Four kinds of serial passthrough mode parameters: Mode FU1 FU2 FU3 FU4 Remark IIDLE 3.5mA 80uA 22mA 22mA Average value Delay 20mS 380ms 2mS 7mS Send a byte Test 1 31mS 8mS 22mS Baud rate:9600,send byte Test 2 31mS 18mS 40mS Baud rate:9600,send 10 bytes AT Instruct: enter into AT instruct mode: ??1.Connect to 3.3V,give low level to the pin 5(keep low),then enter into AT instruct mode. It will exit AT instruct mode when give high level to pin 5. ??2.Power off, pin 5 connect to GND, then power on, after 1 second ,module will enter into AT instruct mode. It will exit AT instruct mode when give high level to pin 5. Instructions as described below: 1. AT Send this instruction, return OK. 2. AT+V Return version information 3. AT + Bxxxx Baud rate is xxxx, it can be 2400,4800,9600,19200,38400,57600,115200 4. AT+Cxxx Set communication channels ,form 001 to 127 5. AT+FUx Switch serial pass through mode, from 1~4 Any problem, please contact us freely 1) We accept PayPal payment ONLY. On Feb-26-15 at 03:11:42 PST, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	HC-11 to TTL
Country/Region of Manufacture	China
Model	CC1101
Type	433Mhz
MPN	433Mhz
UPC	Does not apply
