1pcs Icstation Lc100-a High Precision Digital Inductance Capacitance L/c Meter

US $410

???, ???, China
Jun 9th

Open on mobile:
QR code

Click to Enlarge Click to Enlarge 1PCS ICStation LC100-A High Precision Digital Inductance Capacitance L/C Meter Product Features ICSH014A is a ?Capacitance, Inductance Measuring? module. Engaged in the development of electronic engineers often need to measure inductance and capacitance, and inductance capacitance meter sold on the market price is higher, and the measurement of small capacitance inductance and small error, this instrument based on LC resonant principle, join the accurate measurement of high-speed micro controller calculation, small capacitance can be measured the inductance 1uH and less than 1pF, the maximum this is also the characteristics of the instrument, particularly suitable for microwave production and switching power supply transformer, inductance measurement. ICSH014A (LC module) with four measuring mode: 1.C mode...... Capacitance (0.01pF-10uF). 2.L mode...... Inductance (0.001uH-100mH). 3.HL mode...... Large inductance (0.001mH-100H) 4.HC mode...... Large capacitance (1uF-100mF) All stalls are automatic range, the use is very convenient. In this way, ICSH014A Whether from the measurement range and measurement precision can completely replace any kind of inductance and capacitance measuring instrument on the market, the performance parameters to the digital bridge, is a highly cost-effective instrument. The Technology Parameters Item Parameters Precision of capacitance measurements 0.01pF-1pF 5% 1pF-1uF 1% 1uF-10uF 5% Capacitance measurement resolution(Cx) 0.0 1pF Precision of inductance measurements 0.001uH-1uH 5% 1uH-100mH 1% Inductance measurement resolution(Lx) 0.001uH Precision of large inductance measurements 100mH-1H 1% 1H-100H 5% Inductance measurement resolution(HL) 0.001mH Precision of large Capacitance measurements 1uF -100mF 5% Capacitance measurement resolution(HC) 0.01uF Measurement frequency Lx?Cx 500kHz HL 50kHz Lx ? Cx ? HL measurement method LC oscillation HC measurement method Charge and discharge Display mode LCD1602 The power supply interface MicroUSB and 5VDC socket Power supply voltage 5V Introduction of structure The overall effect diagram . When in use, you can use the Micro USB connection line is connected to the computer USB testing instrument power supply, if the user has a mobile phone charger with USB or with 5V power adapter with DC plug can also be directly to the instrument power supply. Special note: if you are using DC plug adapter, polar please hole positive confirmation, peripheral negative, while the Micro USB interface does not occur polarity error conditions. The structure of the instrument: The button has a total of 5, "Reset" to 0 "HC" button, large capacitance, inductance, select "HL" option, "L/C" and black expansion function button. The HC, HL and L/C selection is self lock , a press release was 1, 0, and X represents the arbitrary function, see the table below: ICSH014A function table HC HL L/C function 0 0 0 Capacitance (Cx) 0 0 1 Inductance (Lx) 0 1 1 Large Inductance (HL) 0 1 0 Error Instructions for use 1. Connecting computer USB as the tester and switch on the power supply. 2. According to the element to be tested for the selection of mode, to choose to measure inductance Lx, capacitance Cx, inductance or capacitance HC HL, in measuring terminal open state from the screen to see: inductance: Measure Lx 0.000uH The capacitive display: Measure Cx 0.00pF Large inductance shows: Measure HL 0.000mH Large capacitor shows: Measure HL 0.00uF 3. Because of the measurement principle of the HC file is different, first stated the following Lx, Cx and HL three mode of operation: In the three mode , the measurements are required for zero adjustment. The methods according to different inductance, capacitance . Cx mode in terminal open state, press "Reset" key, the screen shows "Setting... OK "after the release, the screen time line should display" 0.00pF "; HL and Lx mode, the terminal short-circuit condition, press" Reset "key, the screen shows" Setting... OK "after the release, the screen time should show" 0.000mH "and" 0.000uH ", after the open circuit terminal for display" Over Range!". Then, you can put the inductance connected test instrument to test. In the measuring result displayed, press the function keys are black, will display the test frequency current. 4. In the HC file, please make sure the capacitor is fully discharge to be measured, and then the red test clamp capacitor cathode, black test clamp capacitor anode, read the test results from the display screen and can, need to pay attention to is, the measurement of large capacity (more than 10mF), the test time can be more than 1 seconds, the test time of capacitor the longer the 100mF, about 7-8 seconds before the results. Matters needing attention 1. HC mode measuring electrolytic capacitor, please note the polarity is negative, red black. 2. If the measurements before the display is 0, sometimes also need to zero adjustment, this might be the deviation is negative, but the display will not show negative. 3. Is strictly prohibited in the test terminal element when pressed zeroing button, this operation will lead to the erroneous results. 4. Is strictly prohibited without testing capacitor discharge, otherwise there may result in damage to the meter. 5. To use the 5V adapter module power supply, ensure that the polarity is negative "", otherwise it will damage the module. Thanks Thank you for buying and have a nice time. Other Items You May Need 1pcs ICstation 4.5V-9.9V 0-3A Volt-Ammeter LED Display USB Voltage Ammeter ICStation ICSA009A Step Down Power Supply Module 3.3V/5V for MB-102 Breadboard Step Up Step Down Module DC-DC Converter Automatic 3.5V-28V to 1.25V-26V NEW ICStation ICSA001A 5A Constant Current Constant Voltage Step-down Module CCCV US $4.47 US $2.14 US $5.76 US $5.57 For more quantity,please contact us. 1) We accept PayPal payment ONLY. inkfrog terapeak inkFrog Analytics
