1pcs Mp3 Voice Module U-disk Audio Player Sd Card Voice Module Wtv020-sd-16p

US $160

shenzhen, China
Jan 29th

Open on mobile:
QR code

Product Name: MP3 Voice module U-disk audio player SD card voice module WTV020-SD-16P More Items In Our Store,Click Here! Description 1.product characteristics 1>.The product supports plug-maximum the 1G capacity of the SD card; 2>.Supports playback of 4Bit ADPCM format files; 3>.Automatically recognize the voice files; 4>.Loadable 6KHz to 32KHz, 36KHz sampling rate AD4 audio; 5>.Loadable 6KHz ~ 16KHz sampling rate WAV audio; 6>.16bitDAC and PWM audio output; 7>.Can store up to 512 voice; 8>.WTV020-SD-20S, WTV020-SD-16P two module types; 9>.Support micro-processor and key control; 10>.Voice playback can call any paragraph; 11>.Power-down save operation data capabilities; 12>.Loaded voice without software assistance to the SD card can be placed directly on the voice; 13>.Support file combination play, including mute combination; 14>.Operating voltage: DC2.5 ~ 3.6V; 15>.Quiescent Current: 16uA (SD card is not inserted) 2. Product Overview WTV020-SD module is a voice Rewritable content type of mass storage voice module, pluggable maximum capacity of 1GB SD card memory. Can load WAV format voice, and AD4 formats voice. WTV020-SD module voice chip WTV020SD-20S master core, with MP3 control mode, the key one-to-one control mode (3 voice with the voice two), the power-loop control mode as well as the second-line serial control mode. The control mode is set in the chip of the sample preparation, can not be switched during the operation of the various control modes, such as the need to use what mode control, Division I to build. MP3 control mode: play / stop, and the next one, on one, Volume +, Volume - functions. The key one-to-one control mode (3 paragraphs voice): a key corresponding trigger a voice have to play three voice and adjust the volume subtraction function, all buttons are default trigger pulse not repeat. Key one-to-one control mode (5 paragraphs voice): has three control methods ?, all keys are pulse retriggerable; ? all keys are play / stop trigger (singles not cycle); ? all keys are play / Stop (single cycle). Power-loop control mode: on power, do not need to trigger any I / O port, and direct all voice Autoplay SD card memory, and has the power and memory point play function when power off and then power on automatically the last power to resume playback voice. Two control modes ?, P04 has a pulse play / pause function; ?, P05 has a level play / pause function. Two-wire serial control mode: CLK clock and send the DI the data line by the microcontroller via data control WTV020-SD module. Free to play the voice of any address. Voice combination play this state, can be performed. Voice updates directly through an SD card reader on a PC replacement. The module supports the FAT file system. Support 6KHz to 32KHz, 36KHz sampling rate AD4 voice and 6KHz ~ 16KHz WAV audio sampling rate, can automatically recognize the voice sampling rate, and the voice file format. 3. Applications WTV020-SD module can be used in automotive electronics (anti-theft alarm, parking sensor, GPS navigation systems, electronic dog, central locking), smart home system, home burglar alarm, medical instruments, the human voice prompts, music player, home appliances (cooker , rice cookers, microwave ovens), entertainment devices (game consoles, amusement machine) learning model (Zaojiao, children's audio books), intelligent transportation devices (toll stations, car parks), communication equipment (telephone switches, telephones), industrial control areas (elevators, industrial equipment), toys and other fields . 4.Product default model is serial control mode Material Download NOTE:This module is a little fastidious for card,you need to use HCSD(high-speed card) with original package for it. Maybe you also need the following parts SD Card Module Slot Socket Reader For Arduino ARM MCU NEW.. SD SDHC Secure Digital MMC to SATA Converter Adapter Work Winodws Mac OS Linux.. ISD4004 Speech voice module Speech development Kit NewWay third version. ENC28J60 Network Module . Mini Digital Power Amplifier Board 3W+3W DC AMP Module 5V USB Power Supply. $ 1.48 + free shipping $ 12.71 + free shipping $ 18.36 + free shipping $ 4.17 + free shipping $ 2.92+ free shipping STC(51)-MCU PIC-MCU AVR-MCU ATMEL-MCU STM32-MCU C8051F-MCU MSP430-MCU Crystal Oscillator IC Socket DIY PCB Universal Board Dupont Line Digital tube Buzzer Arduino UNO board PIC Programming unit AVR ATMEL Programming unit Connector Kit USB to TLL Modules Power Modules LCD Modules RS232 TO TLL Moudle For more quantity, please contact us 1) We accept PayPal payment ONLY. inkFrog Analytics On Apr-29-14 at 23:16:13 PDT, seller added the following information:
